This 12V 3/4″ Brass Electric Solenoid Valve N.C. Air Water Fuel designed with a port size of 3/4″ female NPT threaded and heat and oil resistant Viton gasket.  This particular solenoid valve is a two-way, semi-direct lift valve with a normally closed operating position. This two-way indicates that there are two ports in which media flows. This electric solenoid valve made up of industrial-grade brass. Hence this valve features corrosion resistance, more conducive for welding, optimal for higher temperature projects. And also used with gasoline, diesel fuel, kerosene oil, natural gas, air, etc. Highly recommended not to use this valve with projects involving drinking water or other water projects, due to the chemical composition of brass.
This valve manufactured with a VITON seal. VITON said to be the most durable and high-performance rubber material that ensures the ability to resist high temperatures and corrosive chemicals and other fluids like gasoline, diesel fuel, oils, and lubricants. This highly responsive valve capable of open and close in less than 1 second when actuated. That means it will open or close the flow instantaneously when energized or de-energized. Also, it offers a life cycle of this valve is well over a million cycles with proper operating conditions and maintenance. This Electric Solenoid Valve is capable of handling low viscosity fluids below 20 CST. And the orifice size designed as 20mm and the Cv value is 7.6. Moreover, this solenoid valve can withstand pressures up to 101 psi. And temperatures as low as 14°F and as high as 248°F.
PLEASE NOTE: This valve NOT designed as a continuous duty valve and recommended should NOT use continuously for more than 8 hours in a single cycle. Else it will shorten the life of the valve and may cause the core of the valve to burn out
