Development Boards
Arduino CNC Shield v3 Engraving Machine/3D Printer/A4988 driver GRBL compatible
- Coolant enable
- Uses removable Pololu A4988 compatible stepper drivers. (A4988, DRV8825, and others) (Not Included)
- Jumpers to set the Micro-Stepping for the stepper drivers. (Some drivers like the DRV8825 can do up to 1/32 micro-stepping )
- Compact design.
- Stepper Motors can be connected with 4 pin Molex connectors or soldered in place.
- Runs on 12-36V DC. (At the moment only the Pololu DRV8825 drivers can handle up to 36V so please consider the operation voltage when powering the board.)
- Please note that this is an unassembled kit and needs soldering.
- Latest Arduino CNC Shield Version 3.10
- GRBL 0.9 compatible. (Open source firmware that runs on an Arduino UNO that turns G-code commands into stepper signals)
- PWM Spindle and direction pins
- 4-Axis support (X, Y, Z, A-Can duplicate X, Y, Z or do a full 4th axis with custom firmware using pins D12 and D13)
- 2 x End stops for each axis (6 in total)
Raspberry Pi 4 (4GB)
- Broadcom BCM2711, Quad core Cortex-A72 (ARM v8) 64-bit SoC @ 1.5GHz
- 2GB, 4GB or 8GB LPDDR4-3200 SDRAM (depending on model)
- 4 GHz and 5.0 GHz IEEE 802.11ac wireless, Bluetooth 5.0, BLE
- Gigabit Ethernet
- 2 USB 3.0 ports; 2 USB 2.0 ports.
- Raspberry Pi standard 40 pin GPIO header (fully backward compatible with previous boards)
- 2 × micro-HDMI ports (up to 4kp60 supported)
- 2-lane MIPI DSI display port
- 2-lane MIPI CSI camera port
- 4-pole stereo audio and composite video port
- 265 (4kp60 decode), H264 (1080p60 decode, 1080p30 encode)
- OpenGL ES 3.0 graphics
- Micro-SD card slot for loading operating system and data storage
- 5V DC via USB-C connector (minimum 3A*)
- 5V DC via GPIO header (minimum 3A*)
- Power over Ethernet (PoE) enabled (requires separate PoE HAT)
- Operating temperature: 0 – 50 degrees C ambient
UNO R3 +WiFi ATmega328P+ESP8266 Module CH340G Compatible For Arduino Uno
- Microcontroller: ATmega328IC
- Wi-Fi: ESP8266
- USB-TTL converter: CH340G
- Power Output: 5V-800mA
- Power input USB: 5V (500mA max.)
- Power input VIN/DC Jack: 9-24V
- Power Consumption: 5V 800mA
- Logic Level: 5V
- WiFi: 802.11 b/g/n 2.4 GHz
- USB type: Micro USB
- USB Clock Frequency: 16MHz
- Operating Supply Voltage: 5V
- Digital I/O Pins: 14
- Analog I/O pins: 6
- Memory Size: 32Mb
- Interface Type: serial
- Operating temperature: −40С°/+125С°
- Dimensions (L×W)mm: 53.34×68.58
Mega R3 +WiFi ATmega2560+ESP8266 Module CH340G Compatible For Arduino Mega
- Microcontroller:ATmega2560
- IC Wi-Fi : ESP8266
- USB-TTL converter: CH340G
- Power Out: 5V-800mA
- Power Input USB: 5V (500mA max.)
- Power Input VIN/DC Jack: 9-24V
- Power Consumption: 5V 800mA
- Logic Level: 5V
- Wi-Fi 802.11 b/g/n 2.4 GHz
- USB: Micro USB
- Clock Frequency: 16MHz
- Operating Supply Voltage: 5V
- Digital I/O: 54
- Analog I/O: 16
- Memory Size: 256kb
- Data RAM Type/Size: 8Kb
- Data ROM Type/Size: 4Kb
- Interface Type: SerialOTA
- Operating temperature:−40С°/+125С°
- Build in external antenna
- Dimensions:53.361×101.86mm
NODEMCU ESP8266-12 USB CH340
- 11 b/g/n Wi-Fi Direct (P2P), soft-AP
- Power input: 4.5V to 9V (10VMAX), USB-powered
- Transfer rate: 110-460800bps
- Support UART / GPIO data communication interface
- Support Smart Link Smart Networking
- Working temperature: -40°C ~ + 125°C
- Drive Type: Dual high-power H-bridge
- Don’t need to download resetting
- A great set of tools to develop ESP8266
- Flash size: 4MByte
- Integrated TCP/IP protocol stack
- Use CH340G to replace the CP2102.
- Integrated low power 32-bit CPU
- Advanced API for hardware IO, which can dramatically reduce the redundant work for configuring and manipulating hardware.
- Integrated TR switch, balun, LNA, power amplifier, and matching network
- Integrated PLL, regulators, DCXO, and power management units
- On-board USB to serial chip to easily program and upload codes from the Arduino IDE
- Embeds logic level converter circuits
- Has onboard 3.3V regulator to ensure enough power to function as your go-to WiFi chip!
- Easy access to the GPIO pins for easy prototyping
ESP8266 ESP – 01
- 11 b/g/n
- Wi-Fi Direct (P2P), soft-AP
- Integrated TCP/IP protocol stack
- Integrated TR switch, balun, LNA, power amplifier and matching network
- Integrated PLLs, regulators, DCXO and power management units
- +19.5dBm output power in 802.11b mode
- Power down leakage current of <10uA
- 1MB Flash Memory
- Dimensions: 25 x 15 x 11 mm (LxWxH)
- PCB Thickness: 1mm
- Weight: 2 gm
- SDIO 1.1 / 2.0, SPI, UART
- STBC, 1×1 MIMO, 2×1 MIMO
- A-MPDU & A-MSDU aggregation & 0.4ms guard interval
- Wake up and transmit packets in < 2ms
- Standby power consumption of < 1.0mW (DTIM3)
- Integrated low power 32-bit CPU could be used as an application processor
- A-MPDU & A-MSDU aggregation & 0.4ms guard interval
- Wake up and transmit packets in < 2ms
- Standby power consumption of < 1.0mW (DTIM3)
ESP8266 ESP-12E
- LDR Light Sensor on board.
- WS2812 Led on board.
- Wireless Standard: IEEE 802.11 b/g/n protocol
- Frequency Range: 2.412 - 2.484 GHz
- Serial Transmission: 110 - 921600 bps, TCP Client 5
- SDIO 2.0, SPI and UART Interface available
- PWM available
- One ADC channel available
- Programmable GPIO available
- Wireless Network Type: STA / AP / STA + AP
- Security Type: WEP / WPA-PSK / WPA2-PSK
- Encryption Type: WEP64 / WEP128 / TKIP / AES
- Network Protocol: IPv4, TCP / UDP / FTP / HTTP
- Operating Voltage: 3.3V
- Maximum current allowed to draw per pin: 15mA
- Power down leakage current of < 10uA
- Integrated low power 32-bit MCU
- Onboard PCB Antenna
- Wake up and transmit packets in < 2ms
- Standby power consumption of < 1.0mW
- Operating Temperature: -40ºC to +125 ºC
NODMCU Esp8266-12 USB CP2102
- 11 b/g/n Wi-Fi Direct (P2P), soft-AP
- Integrated TCP/IP protocol stack
- CP2102 Serial / USB Chip
- +19.5dBm output power in 802.11b mode
- 4MB Flash Memory
- Integrated low power 32-bit CPU
- SDIO 1.1 / 2.0, SPI, UART
- Dimensions – 49 x 24.5 x 13mm
- Integrated TR switch, balun, LNA, power amplifier and matching network
- Integrated PLLs, regulators, DCXO and power management units
- On board USB to serial chip to easily program and upload codes from the Arduino IDE
- Embeds logic level converter circuits
- Has on board 3.3V regulator to ensure enough power to function as your go-to WiFi chip!
- Easy access to the GPIO pins for easy prototyping
- ESP-12E Processor
- Easy to use breadboard friendly form factor
- Voltage Regulator / Converter, excellent DC to DC conversion, super efficientESP-12E Processor
- Easy to use breadboard friendly form factor
Raspberry pi Zero W
- Broadcom BCM2835 1GHz processor
- 512MB RAM
- 11 b/g/n wireless LAN
- Bluetooth 4.1
- Bluetooth Low Energy (BLE)
- Mini HDMI and USB On-The-Go ports
- Micro USB power
- HAT-compatible 40-pin header
- Composite video and reset headers
- CSI camera connector
- Dimensions : 6.6 x 3.05 x 0.51 cm
- Weight: 9.07 Grams
USBASP PROGRAMMER
- No special USB controller required
- Programming speed is up to 5Kbytes/sec
- Working platform: Linux, Windows, Mac OS X
- Allows to read or write the microcontroller EEPROM, firmware, fuse bits, and lock bits
- No special controllers or smd components needed.
- Target is supported by SCK option with low clock speed (<1.5MHz)
- Programming status and Bus status are easily identified
- Easy interface is achieved by Header pins for various ISP header pins
- Dimension: 63.3*20.5*10.5mm
- Weight: 15gm
USB TO TTL CP2102
- USB 2.0 compliant with full speed of12Mbps
- Baud rate: 300bps to 1.5Mbps
- All handshaking and modem interface signals
- USB transceiver included, without any external circuit
- Support data bit of 8 bit, 1 stop bit and parity bit
- Highly stable and reliable chipset
- 6 pins for 3.3V, RST, TXD, RXD, GND &5v
- 640-byte transmitter buffer
- Event character support line break transmission
- Temperature range: -40 degree to 85 degree Celsius
- Dimension: 42*15mm
- Weight: 4g
ATtiny85 Arduino-enabled Mini USB Dev Board
- Support for the Arduino IDE 1.0+ (OSX/Win/Linux)
- Power via USB or External Source
- Onboard 5V Regulator
- Built-in USB
- 6 I/O Pins
- 8k Flash Memory (about 6k after bootloader)
- I2C and SPI (vis USI)
- PWM on 3 pins (more possible with Software PWM)
- 10-bit ADC
- ADC on 4 pins
- Power LED and Test/Status LED
- Low Power Consumption
- Active Mode:1 MHz, 1.8V: 300 µA
Pro Micro 5V 16M Mini Microcontroller Development Board For Arduino
- ATMEGA32U4 chip
- Supply Voltage: 5VDC
- Frequency: 16Mhz
- Support Arduino IDE V1.0.1
- Four 10 bit ADC pins
- 12 pins Digital I/O(5 PWM capability)
- Micro USB interface programming on the board
- Rx and Tx hardware serial connection
- Dimension: 33mm x 18mm
TL866II Plus Universal USB MiniPro USB Programmer for 15000+IC SPI Flash NAND EEPROM MCU PIC AVR
- High-Speed Programming - 12 Mbps
- Unique ultra-low power consumption
- Portable performance
- Programmable programming power supply
- Best overvoltage, overcurrent protection
- 40-pin universal pin
- Upgrade function
- 54/74F/LS/HC CMOS4000 series IC functional tests
- AVR microcontroller one-to-one soft encryption
- Unified and convenient user interface
- NAND Flash: Yes
- ISP for 24/93/25 MCU: Yes
- 25 NOR Flash Max. Capacity: 512M
- Multiprogramming: 4 programmers
- VPP Max. Voltage: 18 V
- VCC Voltage: 1.8 V to 6.5 V
- W29C020 P+V (s): 10.S+2.4S
- W25X80 P+V (s): 9.3S+1.7S
- W25W64 P+V (s): 69S+14.5S
- Device List: 15,000+
- Support simultaneously burn with 4 Programmers each computer
- Minimum Volume and the lowest Power Consumption and Do not Feel any Heat in Process.
- All chips do not need external power supply, the low power consumption of its own to ensure that the USB port can provide enough power.
- Best internal 40 pin over-voltage protection, the strongest VCC/VPP 4-level overcurrent protection. The short-circuit do not reset the PC.
- Unique serial ICSP interface
- Test CMOS4000 74/54 series integrated circuit. Can be located in the gate circuit error.
- Chip auto serial number is the most complete and practical.
AVR-ISP 10Pin to 6pin Adapter PCB for USBASP Programmer
- Made of high-quality material, practical and durable
- Number of Pinon USBASP side: 10.
- Number of Pinon Device under programming side: 6.
- Connector type on USBASP side: Male.
- Connector type on Device under programming side: Female.
- Header Pin Pitch: 2.54mm (0.1in).
ESP-WROOM-32 universal WiFi-BT-BLE MCU module
- Wi-Fi Protocols: 802.11 b/g/n
- Wi-Fi+BT+BLE MCU Module
- Bluetooth v4.2 BR/EDR and BLE specification
- Wi-Fi mode Station/softAP/SoftAP+station/P2P
- Security WPA/WPA2/WPA2-Enterprise/WPS
- Encryption AES/RSA/ECC/SHA
- Operating voltage: 2.2-3.6V
- Consumption: 80 mA typ
- On Chip Hall Sensor
- Integrated Crystal of 40 MHz
- Integrated SPI Flash of 4 MB
- Recommended Voltage: 3.3V
- Operating Current: Average 80 mA
- ESP32-WROOM-32 contains two low-power Xtensa 32-bit LX6 microprocessors
- 448 KBytes ROM for booting and core functions
- 520 KBytes on-chip SRAM
- 8 KBytes SRAM in RTC SLOW
- 8 KBytes SRAM in RTC FAST
- Dimensions: 18 mm* 25.5 * 2.8 mm
ESP8266 ESP – 03
- Communication interface voltage: 3.3V
- Working current: 240mA(MAX)
- 802.11 b/g/n
- Wi-Fi Direct (P2P), soft-AP
- Integrated TCP/IP protocol stack
- Integrated TR switch, balun, LNA, power amplifier and matching network
- Integrated PLLs, regulators, DCXO and power management units
- +19.5dBm output power in 802.11b mode
- Power down leakage current of <10uA
- Integrated low power 32-bit CPU could be used as application processor
- SDIO 1.1/2.0, SPI, UART
- STBC, 1×1 MIMO, 2×1 MIMO
- A-MPDU & A-MSDU aggregation & 0.4ms guard interval
- Wake up and transmit packets in < 2ms
- Standby power consumption of < 1.0mW (DTIM3)
- SDIO 2.0, SPI, UART
- 32-pin QFN package
- Integrated RF switch, balun, 24dBm PA, DCXO, and PMU
- Integrated RISC processor, on-chip memory and external memory interfaces
- Integrated MAC/baseband processors
- Quality of Service management
- I2S interface for high fidelity audio applications
- On-chip low-dropout linear regulators for all internal supplies
- Proprietary spurious-free clock generation architecture
- Integrated WEP, TKIP, AES, and WAPI engines
ESP8266 ESP-13
- Supply voltage: 3.3V
- Commands: AT + STA can coexist
- Operating Current: 70mA-200mA
- Frequency: 125 KHZ
- Form Factor: 18mm x 20mm
- Wireless Network Mode: station / softAP / SoftAP + station
- Dimension: 19.9*20MM
ESP8266 ESP-12F
- Communication interface voltage: 3.3V
- Working current: 240mA(MAX)
- Serial port baud rate: 115200 (default), can be modified to other values by AT command
- Serial communication format: 8N1
- Wireless Network Mode: station / softAP / SoftAP + station
- Wireless criteria: 802.11 b / g / n
- WIFI @ 2.4 GHz, support for WPA / WPA2 security mode
- +19.5dBm output power
- Compatible with ESP-12(ESP-202)
- It is very easy to develop projects with AT commands
- Surface Mount Package with 2mm Pitch Pads
- Mulitple GPIO’s for all your sensor needs
- Integrated TCP/IP protocol stac
- Integrated TR switch, balun, LNA, power amplifier and matching network
- Integrated PLL, regulators, DCXO and power management unit
- Power down leakage current of <10uA
- Integrated low power 32-bit CPU could be used as an application processor
- SDIO 1.1/2.0, SPI, UART
- STBC, 1×1 MIMO, 2×1 MIMO
- A-MPDU & A-MSDU aggregation & 0.4ms guard interval
- Wake up and transmit packets in < 2ms
- Standby power consumption of < 1.0mW (DTIM3)
- Both SMD and Inline package are available, and the pin pitch is 2.0mm.
Evaluation Board For Pi
- Designed for Raspberry Pi
- UART interface: easily connects to UART modules such as RS232, RS485, USB TO UART, etc.
- 8 I/Os interface: easily connects to modules controlled by I/Os, such as 8 Push Buttons, Logic Level Converter, Mix Board, etc.
- SPI interface: easily connects to SPI modules such as AT45DBXX Data flash, L3G4200D Board, etc.
- I2C interface: easily connects to I2C modules such as PCF8574 Expansion Board, PCF8563 RTC Board, LSM303DLHC Board, etc.
- Character LCD interface: for connecting character LCDs like LCD1602
- USB connector: USB TO UART, supported by onboard converter CP2102
- Power indicator, User LEDs, User Keys
- Potentiometer: for LCD1602 contrast adjustment
- PCF8563 onboard RTC chip with battery holder and crystal
Raspberry Pi Camera Module V2 – 8 Megapixel 1080p
- 8-megapixel native resolution high-quality Sony IMX219 image sensor
- Cameras are capable of 3280 x 2464 pixel static images
- Fixed focus lens on-board
- Supports 1080p30, 720p60 and 640x480p90 video
- Connects to the Raspberry Pi board via a short ribbon cable (supplied)
- Uses the Sony IMX219PQ image sensor – high-speed video imaging and high sensitivity
- All software is supported within the latest version of the Raspbian Operating System
- Supports Raspberry Pi 1,2 and 3
- Dimensions: 25mm x 23mm x 9mm
- Weight: 3.4g
ESP8266-12E 10A 220V NETWORK RELAY WIFI MODULE INPUT DC 7V-30V
- Input voltage: DC 7V-30V
- Relay voltage: 220V
- Relay current: 10A
- ISM: 2.4GHz
- PA: +25dBm
- Input over-voltage protection
- Input overcurrent protection
- ESP8266 WIFI module with 4 layered board design
- LED indicator for input status and output status
- 220V 10A relay, normally opened, and one normally closed
- Optocoupler isolation input, TVS input protection
- Access server control via HTTP protocol by TCP client mode, high current terminals
- Dimension: 65*40*18mm
7” Touch Screen
- 800×480 high resolution.
- Viewable screen size: 155mm x 86mm
- 10 finger capacitive touch
- Supports Raspberry Pi, and the driver is provided (works with custom Raspbian directly).
- Supports BB Black, comes with related images like Angstrom.
- Supports Banana Pi / Banana Pro, comes with related images like ubuntu, Raspbian.
- Connects to the Raspberry Pi board using a ribbon cable connected to the DSI port.
- Adapter board is used to power the display and convert the parallel signals from the display to the serial (DSI) port on the Raspberry Pi.
- Require the latest version of Raspbian OS to operate correctly
- Not only for mini-PCs, but it can also work as a computer monitor just like any other general HDMI screen (touch function is unavailable in this case).
- HDMI interface for displaying, USB interface for touch control.
- Backlight control to lower power consumption.
- Screen Dimensions: 194mm x 110mm x 20mm
Raspberry PI 3 Model B
- Raspberry Pi 3 - Model B Broadcom BCM2387 chipset
- 2GHz Quad-Core ARM Cortex-A53
- 802.11n Wireless LAN and Bluetooth 4.1 (Bluetooth Classic and LE)
- 1GB RAM
- 64 Bit CPU
- 4 x USB ports
- 4 pole Stereo output and Composite video port
- 10/100 BaseT Ethernet socket bar
- Audio Output 3.5mm jack
- CSI camera port for connecting the Raspberry Pi camera
- DSI display port for connecting the Raspberry Pi touch screen display
- Micro SD port for loading your operating system and storing data
- Upgraded switched Micro USB power source up to 2.5A
- Fully HAT compatible
- 40pin extended GPIO to enhance your “real world” projects.
- Stream and watch Hi-definition video output at 1080
- Dimension: 12.19 x 7.59 x 3.4 cm
- Weight: 45 Grams
ESP8266 ESP – 07
- Smallest 802.11b/g/n Wi-Fi SOC module
- Low power 32-bit CPU, can also serve as the application processor
- Up to 160MHz clock speed
- Built-in 10 bit high precision ADC
- Supports UART/GPIO/IIC/PWM/ADC
- SMD-16 package for easy welding
- Integrated Wi-Fi MAC/BB/RF/PA/LNA
- Deep sleep current as low as 20uA
- Embedded LWIP protocol stack
- Supports STA/AP/STA + AP operation mode
- Support Smart Config/AirKiss technology
- UART baudrate up to 4Mbps
- General AT commands can be used quickly
- Supports remote firmware upgrade (FOTA)
- WIFI Direct (P2P),SOFT-AP
- Built-in TCP/IP
- The AT command is perfect,efficient,concise
- Support three modes: AP, STA and AP+STA coexistence mode
- Onboard Chip Antenna
- +19.5dBm output power in 802.11b mode
- Power down leakage current of <10uA
- SDIO 1.1/2.0, SPI, UART
- STBC, 1×1 MIMO, 2×1 MIMO
- A-MPDU & A-MSDU aggregation & 0.4ms guard interval
- Wake up and transmit packets in < 2ms
- Standby power consumption of < 1.0mW (DTIM3)
Aluminum Heatsink Cooler Cooling Kit for Raspberry Pi 3/2 Model 3B+ – 2 Piece
- 3m - Sticker for best adhesiveness to the silicon.
- Best aluminium - ensures best fin efficiency and fin effectiveness.
- Colour: Black.
- Suitable for raspberry pi models a, b, b+, 2, and 3 boards.
- Can be applied with other devices such as the beaglebone.
- Dimensions:
- Teeth Number:
- Compatible with most Raspberry Pi cases
- Compatible with other devices such as the Beaglebone
- Compatible with stepper motors, motor driver boards, etc.
Arduino Mega 2560 Board
- Microcontroller: ATmega2560
- Operating Voltage: 5V
- Input Voltage (recommended): 7-12V
- Input Voltage (limits): 6-20V
- Digital I/O Pins: 54 (of which 15 provide PWM output)
- Analog Input Pins: 16
- DC Current per I/O Pin: 40 mA
- DC Current for 3.3V Pin: 50 mA
- Flash Memory: 128 KB of which 4 KB used by boot loader
- SRAM: 8 KB
- EEPROM: 4 KB
- Clock Speed: 16 MHz
Arduino UNO R3 Clone
- Microcontroller: ATMEGA328
- Operating voltage: 5V
- Input voltage: 7-12V
- Digital I/O: 14 (6 provide PWM outputs)
- Analog inputs: 6
- Flash Memory: 32KB
- SRAM: 2KB
- EEPROM: 1KB
- Clock Speed: 16MHz
- DC Current per I/O Pin: 40 mA
- DC Current for 3.3V Pin: 50 mA
LilyTiny (LilyPad ATTiny85)
- Program Memory Type: Flash
- Program Memory (KB) : 8
- CPU Speed (MIPS): 20
- Data EEPROM (bytes): 512
- Digital Communication Peripherals: 1-SPI, 1-I2C
- Capture/Compare/PWM Peripherals : 5
- Comparators: 1
- Temperature Range (C) : -40 to 85
- Operating Voltage Range (V): 1.8 to 5.5
- Pin count: 8
- Cap Touch Channels : 3
Sensors and Modules
3 Axis Accelerometer ADXL 335
Anti-Corrosion Water Level Sensor with Ball Float Switch
IR Proximity Module using TSOP
LJ12A3-4-Z/BY PNP DC6-36V 8 mm INDUCTIVE PROXIMITY SENSOR
MT8870 DTMF Audio/Speech Decoding Telephone Module
pH Sensor Module & pH electrode Probe for Arduino, AVR, PIC
Drones and Drone Parts
30AMPS ESC DYS
- Input Voltage: 11.1 ~ 11.7 V.
- Constant Current: 30A (Max 40A<10s).
- BEC: 5V/3A.
- Li-Po battery: 2S ~ 3S.
- Ni-MH 4-10 CELLS Auto Detect.
- Separately voltage regulator IC for the microprocessor, providing good anti-jamming capability.
- Used with SimonK updated firmware for Multicopter
- Battery side – Male deans (T) connector.
- Motor side – Female 3.5mm gold connector.
- 30A ESC for BLDC has onboard BEC.
- Developed specifically for multi-rotor use
- Smooth, linear, and precise throttle response
- Extreme low output resistance, super current endurance
- Auto Low Battery Slow down at 3.0V/cell Lipo, cut-off at 2.9V/cell lipo.
- Supported motor speed (Maximum): 210000 RPM (2 poles), 70000 RPM (6 poles), 35000 RPM (12 poles).
- Dimension: 46* 26 * 11mm
- Weight: 23g
5045(5×4.5) SF Propellers 2CW+2CCW-2pair
- Length: 5″.
- Pitch: 4.5″.
- Weight: 22 gm.
- Shaft diameter: 5mm.
- Total length: 5 inch / 125 mm.
- Material: Glass Fiber Nylon
- Durable plastic construction provides both lightness and rigidity.
- 5045(5X4.5) Glass Fiber Nylon Bullnose Black Propellers comes with an Epoxy resin cover.
- Very strong and lightweight.
- Quick to release, quick to attach
- New design propellers, with greater aerodynamic efficiency, good lifting capacity.
- Dimensions: 30 x 6 x 4 cm
- Weight: 26 gm.
7045(7X4.5) Propeller
- Length: 7″
- Pitch: 4.5″
- Weight: 36.5g
- Shaft Diameter: 6mm
- Total Length: 177mm
- Material: ABS
- Durable plastic construction provides both lightness and rigidity.
- 1245(12X4.5) Carbon Fiber Black comes with an Epoxy resin cover.
- Very strong and lightweight.
- Includes set of plastic reducers (3, 3.17, 4, 4.70, 5, 6, 6.25 mm).
- Quick to release, quick to attach
- New design propellers, with greater aerodynamic efficiency, good lifting capacity.
- Dimensions: 30 x 6 x 4 cm
- Weight: 25gm
AfroFlight Naze32 Rev6 Flight Controller Board
- Version: 6 DOF
- Input voltage: Max 16V on input rail and up to 35V 6s on the voltage sense line
- USB on right side
- 32-bit processor running at 3.3V/72MHz (STM32F103CB).
- Up to 8 Ch. RC input - supports standard receivers (PWM), PPM Sum receiver (FrSky, etc), or Spectrum satellite receivers
- Built-in FrSky telemetry inverter
- Battery voltage monitoring
- SBUS Inverter built-in
- Spectrum satellite
- Modern GUI for all operating systems, Baseflight Configurator.
- Supports multiple platforms: Quad/Hexa/Tri/Bi/Y4/Y6/Octo/Camera Gimbal. (Default is Quad-X)
- MPU6500 : 3-Axis MEMS Gyroscope + accelerometer
- Onboard MicroUSB for setup and configuration
- BMP280 barometer
- Modern GUI for all operating systems, Baseflight Configurator.
- Sonar pads w/resistors added for direct connection to 5V sonar3.3V
- Dimensions: 36x36 mm (30.5mm Mounting)
- Weight: 5.3 grams (no headers, 7.3 grams with).
Ardupilot Mega APM 2.8 Flight Controller
- Model: APM 2.8
- Input Voltage (V): 12-16 V.
- Processor: ATMEGA2560 and ATMEGA32U-2
- Micro SD card slot: No.
- Arduino Compatible
- MPU6000 : 3-Axis MEMS Gyroscope + accelerometer
- High-performance Barometer upgraded to MS5611-01BA03, from Measurement Specialties.
- Support hundreds of 3D waypoints
- Full mission scripting with point-and-click desktop utilities
- Two-way telemetry and in-flight command using the powerful MAVLink protocol
- Powerful Ground Control Software
- Supports full "hardware-in-the-loop" simulation with Xplane and Flight Gear
- On-board 4 Megabyte Data flash chip for automatic data logging.
- Optional off-board GPS, an uBlox LEA-6H module with Compass.
- Dimensions: 70 x 45 x 15mm
- Weight: 70gm
CC3D flight Control
- Powerful STM32 32-bit microcontroller running at 90 MIPS with 128KB Flash and 20KB RAM.
- 3-axis high-performance MEMs gyros and 3-axis high-performance MEMs accelerometer.
- Tiny 36 x 36 mm 4 layer PCB for superior electrical noise reduction and flight performance.
- Software support for Windows, Mac, and Linux.
- Supported by powerful OpenPilot GCS
- 10 PWM outputs to servos or ESC’s, or for camera stabilization
- Direct high-speed USB support with no drivers required, a true plug and play device.
- Spectrum satellite receiver support.
- Futaba S-BUS hardware support.
- With a function of being directly plugged into the satellite receiver
- 10 PWM outputs to servos or ESC’s, or for camera stabilization
- Innovative Flexi-port technology for superior port flexibility.
- 4Mbits on-board EEPROM for configuration storage.
F450 Quadcopter Frame
- Model: F450
- Frame width: 450mm
- Frame height: 55mm
- Frame Weight: 282g
- Take-off Weight: 800g ~ 1200g
- Motor Mount Bolt Holes: 16/19mm
- Landing Gear Height: 150mm
- Landing Gear Weight: 90gm
- Made by advanced engineering material, super strong & smooth.
- High quality and strong ability of anti-fall, lower maintenance cost.
- Compact design with small numbers of components, you can assemble it by yourself quickly and easily.
- Recommended Propeller: 10x4.5in;8x4.5in
- Recommended Battery: 3S~4S LiPo
- Recommended Motor: 22x12mm (Stator size)
- Recommended ESC: 20A/30A ESC
F550 HEXACOPTER FRAME
- Model: F550
- Material: Glass Fiber + Polyamide-Nylon
- Wheelbase: 550mm
- Arm Size : 220 x 40mm
- Motor Mounting Hole Diameter: 3mm
- Landing Gear Material: ABS Plastic
- Landing Gear Height (mm): 200
- Landing Gear Color: Black
- Landing Gear Weight: 75gm
- Comes with Black, Red, and White arms for easy orientation during flying
- Plastic injection molding ensures hardness and lighter weight
- Built from high-quality glass fiber and nylon
- Easy to build and assemble
- Made by advanced engineering material, super strong & smooth
- Easy to assemble and disassemble.
- The frame is tough and durable.
- The arm equips support ridges for better and faster forward flight.
- In-built power distribution board.
- Large Center plate allows mounting of gimbals and camera for FPV and aerial photography
- Weight:624gm
FlySky 2.4Ghz 6CH Receiver
- Item Name: FS-R6B Receiver
- Brand Name: Flysky
- Power input: 4.0 -6.5 V DC
- RF power: less than 20DBm
- Modulation: GFSK
- Code type: PCM
- Sensitivity: 1024
- PWM channels: 6
- Protocol: AFHDS
- Distance: >150m
- Antenna type: Built-in antenna
- Low voltage warning: LED
- Charger port
- Certificate: CE,FCC,RoHS
- Dimension: 30*25*8mm
- Weight: 25g
Flysky CT6B 6 Channel
- Channels: 6 Channels
- Operating Voltage: 12V DC (1.5AA x 8 Battery).
- Model type: Heli, Airplane, Glider
- RF Power: Less than 20db
- Modulation: GFSK
- Code Type: 2.4Ghz No Interference
- Sensitivity: 1024.
- Bandwidth: 500 kHz.
- Default Operating Mode: Mode 2 (Left-Hand Throttle).
- Low Voltage Warning: LED
- We can programme by PC with the included software.
- Super active and passive anti-jamming capabilities.
- Very low power consumption.
- 4 Types (Airplane, Heli90, Heli120, Heli140).
- DSC Port: Yes
- Charger Port: Yes
- ANT length: 26mm
- Certificate: CE FCC
- Dimension: 190*80*240mm
- Weight: 680g
Flysky FS-16 6 Channel
- Bandwidth (KHz): 500.
- RF Range (GHz): 2.40 ~ 2.48.
- No. of channels: 6.
- Remote controller weight (gm): 400.
- Power: 6V (1.5V AA*4).
- Antenna Length: 26mm * 2 (dual antenna).
- Transmitting Power: ≤ 20dBm.
- RF Receiver Sensitivity: -105dbm.
- Entry-level 6 channel 2.4GHz radio with telemetry capability.
- Easy to use Programming & Navigation Buttons.
- Supports Heli/Standard Wing/Elevon/V-Tail.
- 20 Model Memory.
- 8 Character Model Name.
- Trainer and charging ports.
- The backlight LCD screen displays real-time transmitter and receiver voltage.
- 4 Stick Mode Selectable.
Flysky FS-TH9X 9Channel With FS-R8B
- Transmitter: FS-TH9X Upgrade with FS-RM003 2.4GHz Module
- Receiver: FS-R8B
- Default Mode: Mode-2
- Input Power: 12V DC (1.5V x 8 AAA Battery)
- Bidirectional System
- Frequencies-Hopping
- Omni-directional High Gain Antenna
- Low Power Consumption
- Colour: Black
- Charger Port: Yes(DC Port)
- Data Output: PPM
- Channel Resolution: 4096
- Channel Delay: Better than 30us
- Display: STN VA-73 39mm LCD
- DSC port: 3.5mm:output:PPM
- Dimension:185*220*110mm
- weight: 690gm
KK-Mini FLIGHT CONTROLLER
- IC: Atmega644 PA
- Gyro/Accelerometer: Auto-level: Yes
- Input Voltage: 4.8-6.0V
- AVR interface: standard 6 pins.
- Signal from Receiver: 1520us (5 channels)
- Signal to ESC: 1520us
- LCD size: 24*18mm
- Mini buttons size: Four 3.3*4.2mm
- Mounting holes: 30.5x30.5mm
- Voltage sensor: One red positive pin header for.
- Input rail: Single row 2.54mm pitch pin header for input signal
- Firmware Version: 1.6
- Dimension: 36x36x11.5mm
KK2.1.5 Flight Control
- IC: Atmega644 PA
- Input Voltage: 4.8V-6.0V.
- AVR Interface: Standard 6 Pin.
- Signal from Receiver: 1520us (5 channels)
- Signal to ESC: 1520us.
- Gyro/Accelerometer: MPU 6050
- Auto Level function
- Firmware Version: 1.6
- Dimension: 50.5mm x 50.5mm x 12mm
Landing Gear
- Color: black
- Material: ABS Plastic
- Length: 200mm
- Ground Clearance:200 mm
- Compatibility: Q450 and S500 Frames
- Good-Quality Landing Gears
- Skidproof landing gears
- Dimensions : 10 x 8 x 4 cm
- Weight:230gm
Mini OSD W/ KV Team MOD For Racing F3 Naze32 Flight Controller RC Drone
- NO DC/DC converter, hence less heating
- FTDI cable compatible pinout
- Standard 6-pin ISP header
- Two LED indicators
- ATmega328P with Arduino bootloader
- MAX7456 monochrome on-screen display
- Pad for an Analog or Digital PWM RSSI signal
- Pad for the connection of a Current Sensor
- ATmega328P with Arduino bootloader
- Standalone, or with APM / Flip / Flip32+ flight controllers
- These modifications allow direct connection of two batteries (up to 4S)
- This hardware take the hardware mods for this firmware, and builds them into an RTF solution.
- This Board can be used just as a normal OSD for APM or it can be used with MWC KV Team Mod.
- Two independent power sections with an LED indicator on each.
- Solder jumpers for combining the power sections
- Solder jumper for PAL video option
- +5V 500mA regulator for up to +12V supply input
- Exposed test points for HSYNC and LOS ATmega328P with Arduino bootloader.
- Dimension: 16 x 16mm
MR.RC 12A ESC
- Input Voltage: 2-3S LIPO
- Working Current: 12A
- Burst current (10S): 15A
- BEC: 5V / 1A Programmable: Yes
- With stable performance, it is practical and durable
- Offer you high compatibility, reliability, and stability
- Throttle range can be set to be compatible with different receivers.
- Equipped with built-in linear BEC or switch BEC.
- Easy to install and convenient to use
- Play a significant role in driving and controlling the motor to complete all kinds of instructions
- Suitable for 250 Mini four-axis and F330 aircraft, etc
- Max speed: 210,000 rpm for 2-pole, 70,000 rpm for 6-pole, 35,000 rpm for 12-pole.
- Dimensions:38 x 20 x 6 mm
- Weight: 30g
Q330 Quadcopter Frame
- Colour: Black & Red
- Wheelbase: 325mm
- Frame Diameter: 330mm
- Frame Spacing: 30mm
- Recommend to use 3S 2200-4000mah Lipo battery
- Glass fiber material on center plates
- Glass-filled nylon arms for increased strength and durability
- Lightweight arm design
- Integrated PDB for easy wiring and tidy installation
- Increased internal space for additional electronics/equipment
- Additional mounting holes for frame upgrades
- Suitable for CC3D\MWC\APM\PIXHAWK\NAZA flight control
- Recommend to use 2204/2205 + 6045propeller + 12A ESC, violate flying recommend to use 2208 motor + 20A ESC + 8045 propeller
- Dimension: 21.5*10.5*5cm
- Weight: 231g
QAV250 Quad-copter Frame
- Item name: QAV250 Frame Kit
- Arm plate thickness: 3mm
- Main material: 3k carbon fiber
- Wheelbase: 250mm
- The arm equips dampers for the safe landing.
- The arm has multiple motor mounting holes.
- Equips vibration-free mounting bracket for FPV camera.
- Recommend Propeller: 5 inch
- Recommend Motor: 1806 2204 2206
- Recommend ESC: 8A-12A
- Recommend Battery: 1300Mah-2200Mah
Motors and Motor Drivers
28BYJ-48 5V Stepper motor
- High-quality stepper motor
- Voltage: DC 5V
- Diameter: 25mm
- Step Angle: 5.625 x 1/64
- Reduction Ratio: 1/64
- Rated voltage : 5VDC
- Number of Phase : 4
- Speed Variation Ratio : 1/64
- Stride Angle : 5.625° /64
- Frequency : 100Hz
- DC resistance : 50Ω±7%(25℃)
- Idle In-traction Frequency : > 600Hz
- Idle Out-traction Frequency : > 1000Hz
- In-traction Torque >34.3mN.m(120Hz)
- Self-positioning Torque >34.3mN.m
- Friction torque : 600-1200 gf.cm
- Pull in torque : 300 gf.cm
- Insulated resistance >10MΩ(500V)
- Insulated electricity power :600VAC/1mA/1s
- Insulation grade :A
- Rise in Temperature <40K(120Hz
- Noise <35dB(120Hz,No load,10cm)
3.7 G Micro Servo SG-90
- Servo Type : Analog Servo
- Servo Weight: 3.7g
- Servo Dimension: 20.0 × 17.6 × 8.0 mm
- Voltage: 4.8 to 6.0V
- Speed : 0.12sec/60o (no load)
- Torque: 0.4kg. cm
- Operating Current: 100mA
- Quiescent current: 1mA
- The width of the dead zone: 10u sec
- Cable length: 165mm
- Plug Type: JR plug
- Temperature Range: -30 to +60 Degree C
4000W 220V AC SCR Voltage Regulator Dimmer Electric Motor Speed Controller
- Input Voltage: 220V AC.
- Maximum Power: 4000W.
- Voltage Regulation: AC 0-220V
- AC frequency: 50-60Hz.
- Rotation hole of 6mm
- SCR Model: BT-800B
- Dimension: : 85*60*40mm
40A DC MOTOR SPEED REGULATOR PWM CONTROLLER 2000W
- Speed controller model: 40A PWM DC motor speed regulator
- Operating voltage: 10V TO 50V
- Peak current: 40A
- Control power: 0.01-2000W
- Quiescent current: 0.025A
- PWM regulation: 5-100%
- PWM frequency: 12KHz
- Operating temperature: -20 degree to 40 degree Celsius
- Stability in working
- High efficiency
- potentiometer used for speed adjustability
- Dimension: 9*5.1mm
- Weight: 95gm
48v 500W BM1418ZXF Brushless Motor
- Rated Operating Voltage: 48V DC.
- Rated Power: 500W.
- Rated Speed: 2800 RPM.
- No Load Speed: 3100 RPM.
- Full Load Current: 13.4A.
- No Load Current: 4.0A.
- Rated Torque: 1.7N.m.
- Efficiency: >75%.
- Gear Speed: 400 RPM.
- Gear Torque: 10N.m.
- Gear Ratio: 6:1.
48v 500W BM1418ZXF Motor Controller
- Rated Voltage: 48 Volt DC.
- Rated Power: 500W.
- Maximum Current: 30 Amps.
- Level Brake: low.
- Current limited: 30A±0.5A.
- Efficiency: ≥83%.
- Consumption: <1.5W.
- Turn The Voltage: 1-4.2V.
- Phase Angle: 120 degrees.
- Includes attachments for motor, accelerator, brake, battery, battery charging, brake light, power lock
59TYD-375-2A AC Synchronous Motor 220VAC 50HZ – 1.6, 5, 12, 20, 40. RPM
- RPM: 40.
- Torque: 5 kgcm.
- Voltage: 12-240 VAC.
- Input Power: <13W
- Max Output Torque: 68kgcm.
- Available RPM: 5, 8, 15, 20, 30, 60.
- Frequency: 50/60Hz.
- Rated Current: 100mA.
- Noise (dB): 42.
- Insulation Class: B.
- Direction of Rotation: CW OR CCW Controlled by Capacitor
- Weight: 580g
59TYD-375-2B AC Synchronous Motor 220VAC 50HZ – 5 RPM
- RPM: 30.
- Torque: 68 kgcm.
- Voltage: 12-240 VAC.
- Input Power: <13W.
- Frequency: 50/60Hz.
- Rated Current: 100mA.
- Noise (dB): 42.
- Insulation Class: B.
- Direction of Rotation: CW OR CCW Controlled by Capacitor. "
- Main Application - beverage machine, blenders, grill, oven, office equipment, household appliances.
- Weight:580g.
5V Step Motor 28BYJ-48-ULN2003
- Rated voltage: 5V DC
- Reduction Ratio: 64:1
- Step Angle: 5.625° /64
- Frequency: 100Hz
- Self-positioning Torque: >34.3mN.m
- No of phase: 4
- Speed variation ratio: 1/64
- Pull-in torque: 300 gf.cm
- Friction torque: 600-1200 gf.cm
- DC resistance: 50Ω±7% (25°C)
- Insulated resistance: >10MΩ (500V)
- Insulated power: 600VAC/1mA/1s
- Rise in Temperature <40K(120Hz
- Noise <35dB(120Hz,No load,10cm
- Stepper motor with a standard interface, when used directly pluggable.
- Four-phase LED indicator which indicates the status of the stepper motor work.
- Compact size stepper motor perfect for small robotics applications.
5V-12V DC Brushless Motor Driver Board Controller
- Type: Voltage Regulator
- Drive voltage: DC 5-l2V
- Work current: ≤ 1.2A
- Speed range: from 0% to 100%
- Phase inversion Control
- Offers Voltage polarity protection and Overcurrent Protection
- Suitable for hard brushless motor, brushless motor drive and other miniature 3 / 4 wire brushless motor without hall
A4988 Stepper Motor
- Operating voltage supply: 8 V to 35 V
- Continuous current per phase: 1 Amp
- Maximum current per phase: 2 Amp
- Minimum logic voltage: 3V
- Maximum logic voltage: 5.5V
- Microstep resolutions: Full, 1/2, 1/4, 1/8, and 1/16
- Logic Voltage supply: 3.3 V to 5 V
- Compatible with 3V3 and 5V microcontrollers
- Our Board comes with 0.1 Ohm Sensor resistors
- Five different step resolutions: full-step, half-step, quarter-step, eighth-step, and sixteenth-step
- The Correct current decay mode (fast decay or slow decay) selected by chopping control
- Over-temperature thermal shutdown, under-voltage lockout, and crossover-current protection
- Short-to-ground and shorted-load protection
- 4-layer, 2 oz copper PCB for improved heat dissipation
- Exposed solderable ground pad below the driver IC on the bottom of the PCB
BF-555 Gear / Geared Motor 60 RPM – High Torque
- Rated Voltage:12v
- RPM: 60 (at 12v)
- Nominal Voltage: 12v
- No- Load Current: 110 mA
- Load Current: 450 mA
- Stall Current: 1.8 A
- Full (Stall) Load Torque: 30 kg cm
- Weight: 500g Approx.
BM1418ZXF 48V 750W Controller for Brushless DC Motor
- Rated Voltage: 48V.
- Rated Output Power: 750W
- Speed after Reduction: 480 RPM
- Rated Speed: 2800 RPM
- Gear Ratio: 1:6
- Throttle: 1-4V.
- Full Load Current: 20A
- No Load Current: 5A
- Rated Torque: 15.36 N.m.
- Load Capacity: Up to 350 KG
- Small and Medium-size E-Tricycle
- Short voltage protection: 31.5±0.5V/42±0.5V.
- Colour: silver.
- Casing material: Aluminium.
- Dimension: 105 x 65 x 32mm
Controller for BM1418ZXF 48V 350W Controller for Brushless DC Motor
- Rated Output Power - 350W
- Rated Voltage - 48V
- DC Speed after Reduction - 480
- RPM Rated Speed - 2800
- RPM Gear Ratio - 1:6
- Full Load Current - 9.4A
- No Load Current - 2.8A
- Rated Torque - 7.2 N.m.
- Application - Small and Medium size E-Tricycle
DC 6 30V 6V 12V 24V 5A PWM Motor Speed Controller with Digital Display
- Material: ABS
- Colour: Black
- Input power supply voltage: 6V-30V DC
- Output current: rated current 5A (maximum 8A, can not be extended)
- PWM frequency: 13kHz
- Duty cycle adjustable: 0%-100%
- Adjustable speed range: 0%-100%
- Fine workmanship and good performance.
- Digital display for duty ratio input
- Easy to use.
- Long service life.
- Suitable for the DC motor (or DC load) within 5A, Peak current 8A.
- Dimension: 78*42*25mm
DM556 Digital Stepper Motor Driver with Micro Stepping 20 to 50V 5.6A
- Good high-speed performance
- Supply voltage: +50VDC
- Output current from 0.5A to 5.6A
- Pulse input frequency up to 200 KHz
- Extremely cost-effective
- Automatic idle-current reduction
- Self-test and Auto-configuration technology TTL compatible and optically isolated input
- Micro step resolutions programmable, from full-step to 102,400 steps/rev
- Suitable for 2-phase and 4-phase motors
- Support PUL/DIR and CW/CCW modes
- Anti-Resonance, provides optimum torque and nulls mid-range instability
- Extra-low motor noise offers excellent quietness
- Over-voltage, over-current protection and phase error protection
FEETECH FT5335M 35kgcm Ultra-High-Torque, High-Voltage Digital Giant Servo
- Digital Giant Servo
- Ultra-high Torque, High voltage
- Speed @ 7.4V: 0.18 sec/60°
- Stall torque @ 7.4V: 40 kg.cm
- Speed @ 6V: 0.20 sec/60°
- Stall torque @ 6V: 35 kg.cm
- Lead length: 12 inch
- Servo horns and associated hardware are included
- Dimension: 62.8 × 32.5 × 55.9 mm.
- Weight: 180 g.
FEETECH FT6560M 65kg Large Scale High Torque Servo
- Model: FT6560M.
- Operating Speed6.0v 0.15 sec/60°.
- Operating Speed7.4v 0.13 sec/60°.
- Stall Torque 6.0v 48 kg.cm.
- Stall Torque 7.4v 62 kg.cm.
- Motor: carbon.
- Control Way: Digital.
- Cable Length: 20cm.
- Gear: 5 metal gears.
- Bearing: 2BB.
- Dead band: 4us.
- Working frequency: 330hz.
- Wire/Color: JR 265 mm/ -Brown +Red S Orange.
- Dimensions: 65.8X30.2X57.4mm.
- Weight: 200 g.
L298 MOTOR DRIVER
- Driver model: L298N 2A
- Driver chip: Double H bridge L298N
- Motor supply voltage: 46V(maximum)
- Motor supply current: 2A(maximum)
- Logic voltage: 5v
- Driver voltage: 5V-35V
- Driver current: 2A
- Logical current: 0-36mA
- Maximum power: 25W
- Current sensor for each motor
- LED indication for power status
- Heat sink for better performance
- Operating temperature: -25 degree to 135 degree Celsius
- Can be interfaced with simple manual switches, TTL logic gates, relays, etc.
- Dimension: 55*60*30mm
- Weight: 33gm
Leadshine DM320C
- Supply voltage up to +30 VDC
- Output current programmable, from 0.3A to 2.0A
- Pulse input frequency up to 70 kHz
- TTL compatible and optically isolated input
- Automatic idle-current reduction
- Suitable for 2-phase and 4-phase motors
- Support PUL/DIR and CW/CCW modes
- Over-voltage, over-current, phase-error protection
- Anti-Resonance provides optimum torque and nulls mid-range instability
- Self-test and Auto-configuration technology offers optimum responses with different motors
- Microstep resolutions programmable, from full-step to 102,400 steps/rev
- Support PUL/DIR and CW/CCW modes
- Over-voltage, over-current, phase-error protection
- Its unique features make the DM320C an ideal solution for applications that require low-speed smoothness
Leadshine DMA860H
- Input voltage: Up to +80VAC or +110VDC.
- Output current Up to 7.2A.
- Pulse input frequency up to 300 KHz.
- Automatic idle-current reduction.
- Over-voltage, over-current protection.
- Suitable for 2-phase and 4-phase motors.
- Support PUL/DIR and CW/CCW modes.
- Operating Temperature : 70 C.
- High performance, cost-effective
- Self-adjustment technology
- Pure-sinusoidal current control technology
- TTL compatible and optically isolated input
- 16 selectable resolutions in decimal and binary, up to 51,200 steps/rev
MACH3 interface board
- Compatible Stepper Motor Driver - Max 5 2-phase Microstep controllers
- Driver type - Pulse and Direction signal control
- Wide input voltage range: 12-24V, and with anti-reverse function.
- Output 0-10V analog voltage for inverter to control the spindle speed.
- Compatible with MACH3, Linux CNC (EMC2) etc. parallel-control CNC software.
- USB power supply and peripherals power phase are separate to protect computer security.
- All the signals are to-isolate which can protect your computer security.
- 5-input interface to define the Limit, Emergence-Stop, Cutter alignment, etc.
- Wide input voltage range: 12-24V, and with anti-reverse function.
- One relay output control interface, accessed by the spindle motor or the air pump, water pump, etc.
- Maximum support 5-axis stepper motor driver controllers
- Output 0-10V analog voltage for the inverter to control the spindle speed.
- All the way to the relay output port, control spindle switch. Output port P17 mouth.
- One relay output control interface, accessed by the spindle motor or the air pump, water pump, etc.
- Weight - Approx. 75g
- Dimensions - 90 * 70 * 20mm
MARSPOWER MX1806 2280KV BLDC Motor
- KV: 2280
- Max thrust: 460g
- No of cells: 2-3S
- Framework: 12N14P
- Suitable Propeller: 5-6”
- Shaft: 2mm
- Minimum ESC Specification: 12A Suggested
- Durable with high quality
- The 0.2mm core to lower load temperature and increase efficiency
- Range of use for DJI F330 ZMR250 H250
- Do every single motor balancing test
- Japan NMB bearings provide low noise and long life
- 2mm spindle selection of Kawasaki, Japan, more efficient, less heat
- NdFeB magnets temperature selection
- MX1806 (positive thread motor)
- FPV all configurations life 7-8 minutes!
- Easy to loosen the nut bombing risk!
- Low center of gravity design
- Long-endurance design
- Dimension: 26.7*23mm
- Weight: 18gm
Mini DC 5A Motor PWM Speed Controller 3-35V Speed Control Switch LED Dimmer
- Operating voltage: DC 3V-35V.
- Output current: 0-5A
- PWM Motor Speed Controller.
- Control power: Maximum 90W.
- Quiescent current: 0.01A (Standby).
- Material: plastic, metal.
- PWM duty cycle: 1%-100%.
- PWM frequency: 10 kHz.
- Shell size: 30mm*24mm *15mm.
N20 Model – 40 RPM DC 12V Torque Gearbox Micro Gear Box Motor
- Reduction ratio: 1:380.
- Nominal Voltage: 6v.
- Voltage Range: 3v to 12v.
- RPM: 40.
- No load Current: 40mA.
- Stall Current: 550mA.
- Stall Torque: 7500 g-cm.
- Ideal for making robots
- Lightweight, high torque, and low RPM.
- Fine craftsmanship, long-lasting, not easy to wear.
- Can easily mount a wheel on the motor’s output shaft
N20 Model – 500 RPM DC 12V Torque Gearbox Micro Gear Box Motor
- Reduction ratio - 1:30.
- Nominal Voltage - 6v
- Voltage Range - 3v to 12v
- RPM - 500
- No load Current - 40mA
- Stall Current - 550mA
- Stall Torque - 400 g-cmIdeal for making robots
- Lightweight, high torque and low RPM.
- Fine craftsmanship, long lasting , not easy to wear.
- Can easily mount a wheel on the motor’s output shaft.
NEMA 17 1.6 kgcm
- Operating Voltage : 12~16 V
- Step Angle : 1.8°
- Holding Torque : 1.6 KgCm
- Operating Voltage : 12 - 16 volts
- Supply Current (A) :0.31 Ampere
- Number of Leads : 6
- Frame Size (mm) : 42 x 42
- Shaft Diameter (mm) : 5
- Shaft Length (mm) : 20
- Input pulse decides the rotation angle of the motor.
- High accuracy of around 3 to 5% a step.
- Provides good starting, stopping and reversing.
- Control of this motor is less costly because of exclusion of complex control circuitry.
- The speed is proportional to the frequency of the input pulses.
NEMA17 STEPPER L CLAMP
- Motor Type: NEMA17
- Most accurate design for NEMA17 Stepper Motor
- Made from High-Quality MS.
- Mounting Holes Size: 4mm
- Max Collar Diameter: 22.1 mm
- Dimensions: 50x48x44 mm
- Weight: 73 gm
Planetary Gear DC Motor with Encoder 12V 11 RPM 10 N-m Torque – TPG36555123000-264KE
• Model: TPG36555123000-264KE
• Motor Type: DC Carbon Brush Motor.
• Gear Ratio: 264 : 1.
• Operating Voltage: 12.V DC
• Rated Current: 0.800.A
• Rated Base Motor: 3000.RPM
• Rated Speed: 11 RPM
• Rated Torque: 10 N-m
• Operating Temperature: -40 °C ~ +100°C.
• Opt. Relative Humidity: 20% ~ 85% RH
• Gear Material: Powder Metallurgy, Steel, POM.
• Housing Material: Metal.
• Motor Body Size (Diameter): 36.mm
• Motor Length: 11.5mm
• Shaft Diameter: 8mm
• Shaft Length: 20mm
• Shaft Type: D-type.
• Motor Weight: 500 gm
• Brushed permanent magnet DC motor.
• Variable speed and reversible.
• Planetary Gear Box.
• Standard brush life of 2000+hours
Planetary Gear DC Motor with Encoder 12V 315 RPM 2.5 N-m Torque – TPG36555126000-19KE
- Model: TPG36555126000-19KE
- Motor Type: DC Carbon Brush Motor.
- Operating Voltage: 12.V DC
- Rated Current: 0.800.A
- Rated Base Motor: RPM
- Rated Speed: 315 RPM
- Rated Torque: 5N-m
- Operating Temperature: -40 °C ~ +100°C.
- Relative Humidity: 20% ~ 85% RH
- Gear Material: Powder Metallurgy, Steel, POM.
- Housing Material: Metal.
- Motor Body Size (Diameter): 36.mm
- Motor Length: 10.8mm
- Shaft Diameter: 8mm
- Shaft Length: 20mm
- Shaft Type: D-type.
- Motor Weight: 500 gm
- Brushed permanent magnet DC motor.
- Variable speed and reversible.
- Planetary Gear Box.
- Standard brush life of 2000+hours
Industrial Components
1 or 4 Inch Keyless Drill Bit Chuck Hex Shank Adapter Converter Quick Change
- Material: Drop Forged #45 Carbon Steel.
- Colour: Silver and Black
- Connecting Shank: 1/4 inch (6mm)
- Clamping Range: 0. 3- 6. 5mm
- Instantly convert impact driver to hold non-quick change drill & driver bits
- Ideal for working in tight places
- Turns any 1/4" cordless power screwdriver into a drill or grinder to quickly switch tasks and keep the job moving
- Keyless chuck finger-tightens for easy bit changes unlimited use in
- Unlimited Use in Automotive, Garages, Warehouses, Offices, Homes Etc.
- Dimension: approx. 6*2.9cm
12V SOLENOID LOCK
- Body Material: Iron
- Holding force: 0.25 kg
- Operating Voltage: 12V.
- Rated Current: 0.8 A.
- Power: 9.6 Watt
- Energized forms: intermittent
- Cable Length: 35 cm (with connector).
- Draws 650mA at 12V, 500 mA at 9V when activated
- High quality ultra-compact electric lock
- Unlocking time: 1s
- Rustproof, durable, safe, convenient to use.
- Suction which tightly sucks the iron, thus locking the door.
- Applicable for being installed in the escape door or
- Dimensions: 54 x 42 x 28 mm
- Weight: 150 gm.
12V SOLENOID VALVE
- Voltage: 12V DC
- Power consumption: 5.4W
- Rated Current: 0.6A
- Operation Mode: NC (Normally Closed)
- Pressure: 0.02 – 0.8MPa
- Max fluid temperature: 100°C
- 1/2" BSP male connections, 2-way normally closed solenoid valve, 12V DC
- Valve orifice: DN 10 mm
- Electrical connection: Fast-on tags
- Compact and convenient.
- Easily installed and serviced
- Precise and reliable.
- Pressure-regulating valve
- Suitable for fluids like water, oil, air. Rated Operating Voltage: 12V DC
150mm 6 inch LCD Digital Electronic Vernier Caliper Gauge Micrometer Measuring Tool Caliper Ruler Digital Caliper Plastic
- Measuring range: 0–100 mm.
- Resolution: 0.1mm.
- Repeatability: 0.1mm.
- Accuracy: + 0.1 mm.
- Maximum measurement speed: 1m/s.
- Power: 1 x 1.5V SR44 (silver oxide cell) battery
- Material: Carbon Fiber
- Internal, external and height dimensions can be easily and accurately measured.
- Zero setting in any position.
- With easy to read large LCD display.
- Handy conversion chart at the back.
- Ideal tool for a broad range of industrial and automotive applications.
- Dimension: 240 x 80 x 12mm
24V Dc 1/2″ Brass Electric Solenoid Valve Water Air Fuels Gas Normal Closed New
- Working Medium: Air, Water, Oil, Gas
- Voltage: DC24V, ±10%
- Operating Type: Directly driven
- State: Normally closed
- Flow bore: 16mm
- CV: 4.8
- Pipe Size: 1/2"
- Operating Viscosity: Under 20CST
- Operating Pressure: 0-10 Kg/cm²
- Working Temperature: -5 degree to 80 degree C
- Voltage: DC24V, ±10%
- Valve Body: Brass
- Electric lifting magnet
- Powerful and compact
- Smooth and flat surface
3 Wires 0.28 inch Digital Voltmeter DC 0-100V Red Light LED Panel Voltage Meter
- Display ON Voltage: 3 V
- Measurable Voltage Range: 0 to 100V
- Current Consumption: 10 mA
- Refresh Speed: 200ms (one time)
- Minimum Input: 3 V
- Highest Input: 30 V
- Accuracy: 0.1 V
- Colour: Red
- Wires: 3
- Operating Temperature: -10 to 60 degree C
- Holes for Mounting: 3 mm
- Very small and lightweight voltmeter module.
- Very handy and easy to use.
- Red LED display.
- Best operates in the working voltage range of 5V to 24V
- Dimension: 13*30*9mm
- Weight: 3gm
30mm-120mm Adjustable Circle Cutter Metal Wood Circle Hole Saw Drill Bit Cutter
- Material: Alloy Steel
- Shape: Air Plane
- Adjustment Range: 30mm-120mm
- Total Length: 16cm/6.30" (Approx.)
- Heavy-duty woodworking construction with longest tool life
- Multi-functions, Very convenient and affordable.
- Having adjustable two sharp blades on both side of the measure-bars.
- Adjustable Plane type design.
- Adjustable Capacity 30mm - 120mm
- Comes with Set of Cutter + Blades + Centre Drills
- Comes with Hex Key and Center Drill Bit
- 2 Changeable Centre bits for thinner or thicker materials freely.
- Used to cut many kinds of materials, such as Plywood, Hardwood, Laminates, Composite, Rubber, Plastic, etc
5 Pieces 6, 10, 13, 16, 19 mm Countersink Power Drill Bit Bore Set for Wood Metal
- Suitable for all hand and power drills
- Contains all popular sizes of countersink bits
- Suitable for hardness lower material, such as wood
- Single edge chamfering device 82°Shank: 1/4" Hex
- Material: HSS
- Surface treatment: Titanium
- Length: 6.35mm (1/4'')
- Suit for aperture chamfering 6mm 6mm 1mm 4mm 10mm 6mm 10mm 2mm 5mm 13mm 6mm 13mm 5mm 9mm 16mm 6mm 16mm 7mm 12mm 19mm 6mm 19mm 8mm 13mm
AC 80 300V 100A Digital LCD Ampere Voltage Meter Ammeter Voltmeter White
- Material: ABS
- Color: White
- Voltage Measurement Range: AC 80-300V
- Current Measurement Range: AC 0-100.0A
- Power supply: < 0.2V*A
- Installation: Embedded installation
- Accuracy: 1% ± 2digit
- Measurement speed: about 2 times per second
- Display type: LCD with blue backlight
- Operating Temperature: 10deg. C ~65deg. C
- Operating Humidity: 35~85 percent RH
- Current Transformer: included
- Widely used in substation automation, distribution automation, test equipment, voltage regulator and so on
- Dimension: Approx. 7x4.1x3.2cm
AC 80- 300V LCD Digital Voltmeter Eu Plug Electric Pen Meters
- Model: DM55 1
- Colour: White
- Material: ABS
- Measuring Accuracy : ±1.5%, ±2 digit
- Number of Digits: 3 Digits
- LCD size: 3.6 * 1.8cm
- LCD Display Colour: Blue
- Suitable for measuring the AC voltage in many place, such as office, factory, laboratory, household and so on
- Plug-in digital voltmeter is widely used in AC 80-300V detection
- Digit Measuring Range: AC 80 300v
- Consume Power: <1w (about every 1200hours consume 1 kilowatt hour)
- Plug Style: Eu
- Dimension: 53 * 38 * 60mm
- Weight: 37g
Chrome Steel Extended 1 or 4 Inch Hex Shank Quick Change Adapter Bit Drill Chuck
- Material: Chrome Vanadium steel
- Shank Type: Hex Shank
- Diameter: 6. 35mm(1/4)
- Length: 60mm.
- Can be used for prolonging different kinds of screwdrivers.
- Built-in magnetic, fast, fastening, greatly improve work efficiency.
- Suitable for electric drill, screwdriver, wind batch transfer using to play the role of releasing bit holder.
- Interface comes with a locking function
- Extension rod can only be fitted with single-ended mouthpiece, but not double-ended mouthpiece.
- Dimension: 60mm
- Weight: 0.025kg
DC 12V KK-P25/20 5KG Lifting Solenoid Electromagnet
- Operating Voltage: 12V DC.
- Lifting Capacity: 5KG.
- Electric lifting magnet.
- Powerful and compact.
- Smooth and flat surface.
- Low consumption and reliability.
- Ambient temperature within 130 degrees.
- High mechanical strength and excellent durability
- Minimized residual magnetic force
- Lightweight, compact design for space-saving.
- Dimension: 25 x 20 mm.
DC 24V Solenoid Air Valve 5 Port 2 Position 4V210 08
- Media: air.
- Working Pressure: 0. 17~0. 7Mpa max.
- Pressure resistance: 1. 05Mpa.
- Fluid temperature: 5 50¡¦
- Effective Sectional area 16mm2 (cv=0. 78)
- Joint pipe bore inlet=outlet=1/4 inch,
- Exhaust=1/8 inch.
- Hole: r/s thread (g1/8): approx. 9. 7Mm or 0. 38Inch,
- P Thread (g1/4): approx. 12. 7Mm or 0. 5Inch
- A, B Thread (g1/4): approx. 12. 7Mm or 0. 5Inch.
- Valve body: brass.
Diamond Coated Core Hole Saw Drill Bit Tools for Tiles Marble Glass (5mm 6mm 8mm 10mm 12mm) – Set of 5
- Type: Core drill bit.
- Material: Nickel Plated
- Coating: Diamond
- Diy supplies: Electrical
- Perfect for Cutting Accurate Holes in Glass And Ceramics.
- Heavy-duty hole saws plated with nickel with diamond coating gives a superior performance on ceramic tile and similar material.
- Sizes: 5/32", 1/4", 5/16", 3/8", 1/2"(5mm 6mm 8mm 10mm 12mm)
Digital Voltmeter Ammeter DC 0-100V 10A Dual LED Monitor Panel, Red and Blue
- Input Voltage: 4.5V to 30V DC
- Input Current: <= 20mA
- Display Colour: Red (Voltage), Blue (Current)
- Measuring Voltage Range: 0V to 100V DC
- Measuring Current Range: 0A to 10A
- Measurement Accuracy: 1%
- Minimum Voltage Resolution: 0.1V
- Minimum Current Resolution: 0.01A
- Voltage error: ±0.1%
- Current error: ±1%
- Working temperature: -10℃ to 65℃. Blue
- 28’’ device with 5 wires divided into 2 sets.
- Black, Red are for power supply and 3 wires to measure the Voltage and Current.
- Dimension: 48mm x 29mm x 22mm
Drillpro 290mm Drill Bits Accessories Electric Drill Tools Flexible Shaft Bits Extension Screwdriver Drill Bit Power Tool
- Material: Plastic + metal.
- Full length: 295mm.
- Flexible shaft dimensions:
- Hex shank: 6.35mm (1/4"").
- Inner hexagon head: 6.35mm (1/4").
- Colour: Black.
- This Flexible shaft can be used for general formula hand drill chuck
- Used for the electric screwdriver.
- Flexible shaft head can be mounted hexagonal shank (1/4 handle) the first batch
- Widely used in computer chassis, electrical cabinets, furniture, electrical appliances and other narrow space screwdriver cannot work in an environment operations.
JF-0630B DC 24 V 300mA 10mm 6N Push Pull Solenoid Electromagnet
- Model: JF-0630B
- Rated Voltage: DC 24V
- Type: Pull Push
- Rated Current: 300mA
- Force & Stroke: 6N/10mm
- Body Size: 30 x 20 x 18mm
- Plunger Bar Size : 7 x 58mm
- Mounting Hole Diameter : 2.5mm
- Cable Length: 19cm
- Weight: 46g
- Iron Body Material
- High quality ultra-compact electric lock.
- Rustproof, durable, safe, convenient to use.
- Suction which tightly sucks the iron, thus locking the door.
- Designed with the open frame type and mount board, high power.
- being installed in the escape door or fire door electronic controlled system.
- Adopts the principle of electric magnetism, when the current through the silicon, the electromagnetic lock will achieve a strong
Mini 0.36 Digital Voltmeter DC 4.7-32V 2 Wires Voltage Panel Meter LED Display – Red
- Measurement range: 4.7V to 30V DC
- Only 2 wires, derives supply from the source
- Operation current: < 30mA
- Display colour: RED
- Measurement Error tolerance: +/- 2 percent
- Distance between mounting holes: 26mm
- Current Consumption: < 15 mA.
- Accuracy: 0.1 V.
- Wire length: 18cm.
- Refresh Speed : Approx. 200mS/time.
- Very small and lightweight voltmeter module.
- Very handy and easy to use.
- LED display.
- Best operates in the working voltage range of 5V to 24V
- Dimension: 30mm x 12mm x 8.5mm
Mini Electric Drill Chuck 0.3-4mm Jto Taper-Mounted Lathe PCB Drill Press for Motor Shaft Connecting Rod 3.17mm
- High precision screw thread and tapered hole.
- Strong impact resistance.
- Compatible with impact drill and different power electric drill.
- jt0 taper the biggest end of diameter: 6. 350mm
- jt0 taper the smallest end of diameter: 5. 800mm
- Outer diameter: 21. 5mm
- Drill Clip aperture: 6mm
- Taper type outside diameter drill chuck: 21mm
- Clamping range: 0. 3mm-4mm drill,
- Maximum clamping: 4.2mm
- Fit motor shaft diameter 3. 17mm
- Connection size: jt0 (inner hole diameter is 6 mm) for milling machine, lathe, drilling machine, wood working machine
Pack of 50 pcs Standard Metal HSS Twist Drill Bits Straight Shank
- Model: Twist Drill Bit
- Surface Treatment: Titanium Coating
- Design: straight shank
- Material: HSS
- Size: 1mm*34mm, 1.5mm*38mm, 2mm*45mm, 2.5mm*55mm, 3.0mm*65mm
- Suitable for wood, aluminium, plastic.
- Straight shank design is more suitable for many electric drills sharp and twisted flute will make the drilling be more easy and effortless
PCB DRILL SET
- Length: 185mm
- Sizes: 0.3 mm, 0.35mm, 0.4mm, 0.45mm, 0.5mm, 0.55mm, 0.6mm, 0.65mm, 0.7mm, 0.75mm, 0.8mm, 0.85mm, 0.9mm, 0.95mm, 1.0mm, 1.2mm, 1.3mm, 1.4mm, 1.5mm, 1.6mm
- Supplied with collets giving a capacity of 0-2mm.
- Highly resistant
- Hard
- Greater cutting speed than carbon steel
Soldering Iron Stand
- Universal holder
- Superior sponge Soldering Stand
- Nickel-plated wide spring holder
- Robust and powerful base to uphold the weight of soldering irons varying from 30w, 35w, 40w, 50w, 60w and 75w
- The wide spring holder provides plentiful room for holding the soldering iron support.
- Hollow base - Only sides are in contact with the work surface
- Spring Holder Length: 100mm
- Centre Hole Dia. : 23mm
- Inner Cup Size: 32mm
- Size : 10 x 6.7 x 1.8 cm
- Weight: 106 gm.
Solid State Relay Module DC To AC SSR-40DA 3-32VDC/24-380VAC 40A
- Control mode: DC-AC
- Input voltage: 3-32V DC.
- Output voltage: 24-380V AC.
- Output current: 40A.
- Working voltage: 250V.
- Material: plastic + metal.
- Loading current: 40A
- Control current: 3-25mA DC
- On voltage: ≤1.5V AC
- One-off Time: ≤10ms
- Off leakage Current: ≤2mA
- Dielectrics voltage-resistance: 2500VAC
- Environment temperature: -30 to +75
- Long service life and high reliability.
- Reduced electromagnetic interference.
- Highly reliable, compact size designed to offer users maximum simplicity.
Solid State Relay Module SSR-25DA 25A /250V 3-32V DC Input 24-380VAC Output
- Control mode: DC-AC
- Input voltage: 3-32V DC.
- Output voltage: 24-380V AC.
- Output current: 25A.
- Working voltage: 250V.
- Material: plastic + metal.
- Environment temperature: -30 to +75
- Long service life and high reliability.
- Reduced electromagnetic interference.
- Highly reliable, compact size designed to offer users maximum simplicity.
- Dimension: 6. 5Cm x 4. 5Cm x 2. 2Cm
Solid State Relay SSR-40DD 40A 3-32V DC to 5-60V DC SSR 40DD Relay Solid State
- Model: SSR-40 DD.
- Control mode: DC-DC
- Input voltage: 3-32V DC.
- Output voltage: 5-60V DC.
- Output current: 40A.
- On voltage: ≤1v.
- One-off time: ≤10ms.
- Off leakage current: ≤2ma.
- Loading current: 40A
- Control current: 3-25mA DC
- Material: plastic + metal.
- Environment temperature: -30 to +75
- Long service life and high reliability.
- Reduced electromagnetic interference.
- Highly reliable, compact size designed to offer users maximum simplicity.
- Weight: 0. 106Kg.
Triangular Shank HSS Step Cone Drill Titanium Bit Hole Cutter 1 or 4 1 3 or 8 Inch
- Material: High Speed Steel Hss Steel.
- Super-hard titanium coating lasts up to six times longer than high-speed steel
- Self-starting point starts on contact
- Titanium reduces heat for longer life
- Anti-skid tip eliminates the need for center punching or pilot hole drilling.
- Deburring, chamfering, elliptic hole enlargement, twist drill, the function of them was unable, but it is possible
- Applicable scope: wood working punch
- Size: 1/4 1 3/8 (1/3/1/5/3/7/1 1/1 1/1 3/8)

Fast Delivery

Customer Support

Safe and Clean

Quality Products
