28BYJ-48 5V Stepper motor
- High-quality stepper motor
- Voltage: DC 5V
- Diameter: 25mm
- Step Angle: 5.625 x 1/64
- Reduction Ratio: 1/64
- Rated voltage ： 5VDC
- Number of Phase ： 4
- Speed Variation Ratio ： 1/64
- Stride Angle ： 5.625° /64
- Frequency : 100Hz
- DC resistance ： 50Ω±7%(25℃)
- Idle In-traction Frequency : > 600Hz
- Idle Out-traction Frequency : > 1000Hz
- In-traction Torque >34.3mN.m(120Hz)
- Self-positioning Torque >34.3mN.m
- Friction torque : 600-1200 gf.cm
- Pull in torque : 300 gf.cm
- Insulated resistance >10MΩ(500V)
- Insulated electricity power ：600VAC/1mA/1s
- Insulation grade ：A
- Rise in Temperature <40K(120Hz
- Noise <35dB(120Hz,No load,10cm)
4000W 220V AC SCR Voltage Regulator Dimmer Electric Motor Speed Controller
48v 500W BM1418ZXF Brushless Motor
48v 500W BM1418ZXF Motor Controller
- Rated Voltage: 48 Volt DC.
- Rated Power: 500W.
- Maximum Current: 30 Amps.
- Level Brake: low.
- Current limited: 30A±0.5A.
- Efficiency: ≥83%.
- Consumption: <1.5W.
- Turn The Voltage: 1-4.2V.
- Phase Angle: 120 degrees.
- Includes attachments for motor, accelerator, brake, battery, battery charging, brake light, power lock
59TYD-375-2A AC Synchronous Motor 220VAC 50HZ – 1.6, 5, 12, 20, 40. RPM
59TYD-375-2B AC Synchronous Motor 220VAC 50HZ – 5 RPM
- RPM: 30.
- Torque: 68 kgcm.
- Voltage: 12-240 VAC.
- Input Power: <13W.
- Frequency: 50/60Hz.
- Rated Current: 100mA.
- Noise (dB): 42.
- Insulation Class: B.
- Direction of Rotation: CW OR CCW Controlled by Capacitor. "
- Main Application - beverage machine, blenders, grill, oven, office equipment, household appliances.
- Weight:580g.
5V Stepper Motor 28BYJ-48 with ULN2003
- Rated voltage: 5V DC
- Reduction Ratio: 64:1
- Step Angle: 5.625° /64
- Frequency: 100Hz
- Self-positioning Torque: >34.3mN.m
- No of phase: 4
- Speed variation ratio: 1/64
- Pull-in torque: 300 gf.cm
- Friction torque: 600-1200 gf.cm
- DC resistance: 50Ω±7% (25°C)
- Insulated resistance: >10MΩ (500V)
- Insulated power: 600VAC/1mA/1s
- Rise in Temperature <40K(120Hz
- Noise <35dB(120Hz,No load,10cm
- Stepper motor with a standard interface, when used directly pluggable.
- Four-phase LED indicator which indicates the status of the stepper motor work.
- Compact size stepper motor perfect for small robotics applications.
5V-12V DC Brushless Motor Driver Board Controller
- Type: Voltage Regulator
- Drive voltage: DC 5-l2V
- Work current: ≤ 1.2A
- Speed range: from 0% to 100%
- Phase inversion Control
- Offers Voltage polarity protection and Overcurrent Protection
- Suitable for hard brushless motor, brushless motor drive and other miniature 3 / 4 wire brushless motor without hall
A4988 Stepper Motor
- Operating voltage supply: 8 V to 35 V
- Continuous current per phase: 1 Amp
- Maximum current per phase: 2 Amp
- Minimum logic voltage: 3V
- Maximum logic voltage: 5.5V
- Microstep resolutions: Full, 1/2, 1/4, 1/8, and 1/16
- Logic Voltage supply: 3.3 V to 5 V
- Compatible with 3V3 and 5V microcontrollers
- Our Board comes with 0.1 Ohm Sensor resistors
- Five different step resolutions: full-step, half-step, quarter-step, eighth-step, and sixteenth-step
- The Correct current decay mode (fast decay or slow decay) is selected by chopping the control
- Over-temperature thermal shutdown, under-voltage lockout, and crossover-current protection
- Short-to-ground and shorted-load protection
- 4-layer, 2 oz copper PCB for improved heat dissipation
- Exposed solderable ground pad below the driver IC on the bottom of the PCB
BF-555 Gear / Geared Motor 60 RPM – High Torque
BM1418ZXF 48V 750W Controller for Brushless DC Motor
- Rated Voltage: 48V.
- Rated Output Power: 750W
- Speed after Reduction: 480 RPM
- Rated Speed: 2800 RPM
- Gear Ratio: 1:6
- Throttle: 1-4V.
- Full Load Current: 20A
- No Load Current: 5A
- Rated Torque: 15.36 N.m.
- Load Capacity: Up to 350 KG
- Small and Medium-size E-Tricycle
- Short voltage protection: 31.5±0.5V/42±0.5V.
- Colour: silver.
- Casing material: Aluminium.
- Dimension: 105 x 65 x 32mm
