100 RPM L-Shape BO Motor
- Low density: lightweight, low inertia.
- Capability to absorb shock and vibration as a result of elastic compliance.
- Ability to operate with minimum or no lubrication, due to inherent lubricity.
- The relatively low coefficient of friction.
- Operating Voltage: 3~12 V DC
- Shaft Length: 8.5mm
- Shaft Diameter: 5.5mm (Double D-type)
- No Load Current: 40-180mA.
- Rated Speed(After Reduction): 100 RPM
- Rated Torque: 1 Kgcm
- Cost-effectiveness of the injection-molding process.
- Elimination of machining operations.
- Low density: lightweight, low inertia.
- Uniformity of parts.
- Capability to absorb shock and vibration as a result of elastic compliance.
- Ability to operate with minimum or no lubrication, due to inherent lubricity.
- The relatively low coefficient of friction.
- Corrosion-resistance; elimination of plating, or protective coatings.
- The quietness of operation.
- Tolerances often less critical than for metal gears, due in part to their greater resilience.
- Consistency with the trend to greater use of plastic housings and other components.
28BYJ-48 5V Stepper motor
- High-quality stepper motor
- Voltage: DC 5V
- Diameter: 25mm
- Step Angle: 5.625 x 1/64
- Reduction Ratio: 1/64
- Rated voltage ： 5VDC
- Number of Phase ： 4
- Speed Variation Ratio ： 1/64
- Stride Angle ： 5.625° /64
- Frequency : 100Hz
- DC resistance ： 50Ω±7%(25℃)
- Idle In-traction Frequency : > 600Hz
- Idle Out-traction Frequency : > 1000Hz
- In-traction Torque >34.3mN.m(120Hz)
- Self-positioning Torque >34.3mN.m
- Friction torque : 600-1200 gf.cm
- Pull in torque : 300 gf.cm
- Insulated resistance >10MΩ(500V)
- Insulated electricity power ：600VAC/1mA/1s
- Insulation grade ：A
- Rise in Temperature <40K(120Hz
- Noise <35dB(120Hz,No load,10cm)
49TYD-500 Synchronous 5 RPM AC220/240V AC Motor
500 RPM CS Gear Motor
Metal Gear Servo Motor GS-5515MG
- Control System: Positive PWM control (1500 usec neutral)
- Operation Voltage Range: 4.8V - 0V
- Operation Temperature Range: -20 C - +60 degree C
- Test Voltage:
- Standing Torque@ 4.8V: 13kg-cm
- Speed@ 4.8V : 0.31 sec / 60 at no load
- Idle Current@ 4.8V: 250mA at stopped
- Running Current@ 4.8V: 2000mA at no load
- Standing Torque@ 6.0V: 15kg-cm
- Speed@ 6.0V: 0.28 sec / 60 at no load
- Idle Current@ 6.0V: 300mA at stopped
- Running Current@ 6.0V: 2200mA at no load
- Dead Band Width: 8 usec
- Circle: 10000 times
- Direction: Re-clock wise/ pulse travel 1500 to 1900 usec
- Drive type: FET drive
- Motor Type: Carbon brush
- Size: 41.2*20.2*37.7 mm
- Weight: 63g without splined horn
- Ball Bearing: Double ball bearing
- Gear Material: Metal gear
- Case Material: Nylon plus fiber
- Connector Wire Length: 300mm
- Connector Wire Gauge: 22AWG heavy duty (Futaba universal)
Motor Type 3V-4.5V Cell Phone Micro Vibrator
Vibrator Motor Button Type
- Rated voltage: 3.0VDC
- Maximum Working Voltage Limits: 2.5-4.0VDC
- Rated load: eccentric hammer
- Rated speed: 12000+/-2500RPM
- Rated current: 70mA Max
- Stall current: 120mA Max
- Insulation resistance: 10M ohms Min
- Terminal resistance: 30 ohms
- Small size makes it easy to mount in or on your project
- Low noise level enables feedback without unwanted distractions
- Rotates both CW and CCW for ease of use and installation
