“2WD Mini Round Double-Deck Smart Robot Car Chassis DIY Kit No battery”
1 meter 7 x 7 mm Cable drag Chain Wire Carrier With End Fits
3PI miniQ Car wheel Tyre 42mm N20 DC Gear Motor Wheel
4 Wheel Metal Chassis Grey for Robotics
- Dimensions: 194x 104 x 48 (LxWxH).
- Weight: 270 gm.
- Material: Metal sheet.
- Colour: Grey.
- Sheet Thickness: 1.5 mm.
- Many perforated holes have given for easy attachment of development board and sensors.
- High durable, non-flexible
- Lightweight
- Can be re-shaped easily
- Resistant to corrosion
- Highly rigid
- Compatible with a single type of screw
- The chassis support one rotary castor wheel for balancing the robot & to rotate easily.
4-wheel Robot Smart Car Chassis Kits Car Model with Speed Encoder
- Operating Voltage: 3-6V VDC
- Gear Ratio: 1:48
- No-load speed(5V): about 200 RPM
- Rated Torque: 0.8 Kg.cm @ 5V
- Load current: 170mA (when it is 4.5V)
- Shaft Length: 10 mm
- Shaft Type: 6 mm, Double-D
- Loading Capacity: Max 2.5Kg
- Wheel Diameter: 65 mm
- Wheel Width: 27 mm
- Body Material: Plastic
- Grip Material: Rubber
- Very handy and simple in assembling/disassembling.
- Strong components so as to withstand extreme terrain conditions.
- Transparent Car Chassis.
- Attractive design.
- Double-layer structure, much of mounting holes, enough space
- Easy to install a variety of control panels, sensors
- Simple mechanical structure, easy for installation.
- Adopts 4 DC motors for better power, speed and load capacity
- Easy interface with Arduino development platform
- Enormous space between middle & bottom chasis
Advance Metal Chassis 1
- Dimensions: 115mm x 105mm x 45mm
- Weight: 200 gm
- Material: Metal sheet
- Color: Red.
- Sheet Thickness: 1.5 mm.
- Motor Fitting Hole Diameter: 13.75 mm.
- Many perforated holes have given for easy attachment of development board and sensors.
- Center Shaft gear motor and side shaft gear motor can be used for this chassis.
CYS-S8218 40 kg High Torque Digital Servo
- Control System: Pulse Width Control 1500usec Neutral
- High precision metal gear
- Suit for 1/5 RC car
- Material: aluminum alloy
- Operating Voltage: 6.0~7.4Volts
- Operating Temperature Range: (-)10 to +50 degree C
- Operating Speed (6.0V): 0.20sec/60° at no load
- Operating Speed (7.4V): 0.18sec/60° at no load
- Stall Torque (6.0V): 36kg.cm
- Stall Torque (7.4V): 38kg.cm
- Operating Temperature Range: (-)10 to +50 degree C
- Dead Band Width: 4usec
- Motor Type: NdFeB motor
- Bearing Type: Dual Ball Bearing
- Connector wire: about 300mm
- Size: 59.5*29*55.2mm
- Weight: 164g
DIY D2-5 Intelligent Tracing Car Kit
- Model: D2-5
- Name: D2-5 Intelligent Tracking Car DIY Kit
- PCB Size:104*72*1.6mm
- Installation dimension:104*72*55mm
- Work Voltage:3V
- Easy to Assemble
- The battery is not included
- Self-assembly required
- Without the battery.
- Mini Size, convenient to store and carry
- It can improve children's abilities of creativity and practice
- Material: ABS
Eachine RatingKing F14 1000TVL CCD 110 Degree Mini FPV Camera 411008 1/14 RC Car Part
- Brand: Eachine.
- Item: 1000TVL CCD 110 Degree Mini FPV Camera 411008.
- Input Voltage: 5V.
- Power Consumption: 55mA@ 5v.
- Lux: 0.08Lux/ F1.2.
- Sensor: 1/3 "CCD.
- Format: NTSC/PAL (Free switch).
- Resolution: Ultra High Definition 1000TVL.
- PAL: 976H X 582V.
- NTSC: 976H X 494V.
- Lens: 2.8mm IR coated.
- FOV: 110 °.
- Operating temperature: 0 to 40°C.
- With 1/3'' CCD sensor.
- With lens cover,well protecting the lens.
- With WRD function in default.
- Without OSD.
- Super lightweight, ultra-low power consumption
- Camera size: 28 * 24.5 * 17.5mm.
- Len Size: 17mm *14mm.
- Net Weight: 10g
KFL08 Zinc Alloy Pillow Block Flange Bearing 8mm Inner Diameter Flange Bearing
- Model Number: KFL08
- Material: Zinc Alloy
- Inner diameter: 8mm
- Length: 48mm
- Height: 12mm
- It inserts in housing work as a unit bearing.
- Housing is mainly casting or pressed steel.
- Bearing units are compact in design with perfect sealing devices.
- Light weight and high finish as it is made from Zinc Alloy.
- Anti-corrosive properties due to the high quality alloy material.
- Very stable even at high speeds of rotation.
- Low Noise generation even at higher speeds.
- Highly durable and long life in industrial working conditions.
- The bearing is closed on both sides to prevent dust and contamination.
- Weight: 26.4g
Metal mechanical Arm Gripper claw
- Metal Gripper Robotic Arm
- Operating Voltage: 4.8V to 6.6V
- Material: Aluminum Alloy
- The Kit comes with hardware, unassembly
- Clamp Max open: 55mm
- Clamp total length:108mm
- Clamp total width:98mm (when the Clamp open
- Light weight plank kit
- Compatible with HS322, HS422, MG995, SG5010 servo
- Degree of Freedom (DOF): 2
- Bearing Type: Ball Bearing
- Weight: About 68g
