ACS712 5A current sensor module
The ACS712 5A Current Sensor Module is a Hall-effect-based sensor for accurate AC/DC current measurement up to ±5A in embedded projects.
Description
The ACS712 5A Current Sensor Module is a reliable Hall-effect–based sensor designed to measure AC and DC currents up to ±5A. It provides accurate, isolated current sensing, making it ideal for power monitoring, overcurrent protection, and energy measurement projects.
The module outputs an analog voltage proportional to the current, which can be easily read by microcontrollers such as Arduino, ESP32, STM32, and PIC using an ADC pin. Thanks to its electrical isolation, it ensures safe current measurement without direct electrical connection to the load.
With its compact, breadboard-friendly design and low noise characteristics, the ACS712 5A module is widely used in battery monitoring systems, motor control, inverter projects, solar power systems, and educational electronics labs.
Reviews (0)
Shipping & Delivery
Related products
Arduino CNC Shield
- Shield type:Â Arduino Nano
- Firmware:Â GRBL
- Modular stepper motor drivers:Â 3
- Limit switches:Â 6
- Micro-stepping:Â 1/16
- Coolant enable
- Uses removable Pololu A4988 compatible stepper drivers. (A4988, DRV8825, and others) (Not Included)
- Jumpers to set the Micro-Stepping for the stepper drivers. (Some drivers like the DRV8825 can do up to 1/32 micro-stepping )
- Compact design.
- Runs on 12-36V DC. (At the moment only the Pololu DRV8825 drivers can handle up to 36V so please consider the operation voltage when powering the board.)
- Please note that this is an unassembled kit and needs soldering.
- Latest Arduino CNC Shield Version 3.51
Arduino LilyPad 328 ATmega328P Main Board 16M Compatible with Arduino
- Microcontroller: ATmega168 or ATmega328V
- Operating Voltage: 2.7-5.5 V
- Digital I/O Pins: 14
- PWM Channels: 6
- Analog Input Channels: 6
- DC Current per I/O Pin: 40 mA
- Board will run from 2V to 5V.
- The latest version of the LilyPad supports automatic reset for even easier programming.
- The back side of the LilyPad is now completely flat!
WH0201102 ABS 1.75 mm 1 kg Filament-Wanhao
- Material: ABS
- Color: White
- Material Diameter: 1.75mm
- Printing Temperature: 220° to 230°C
- Roundness Accuracy: +/- 0.5mm +/- 0.5mm
- Density: 1.31g/cm3 1.01g/cm3
- Mounted: Spool Mounted
- Net weight: 1kg
- Packaging Vacuum-sealed with desiccant to protect the filament from humidity
- Highly Detailed & Quality Outputs.
- Tried and Tested by Makenica.com
- Compatible with any FDM 3D Printer.
- ABS is stronger than PLA
- Easy to post-process.
- Environment friendly – ISO 9001 and ROHS certified
