Creality 3D CR-10S DIY 3D Printer Kit 300*300*400mm Printing Size
₹32,000.00 Original price was: ₹32,000.00.₹30,000.00Current price is: ₹30,000.00. inc. GST
- Printing size: 300*300*400mm
- Printing type: FDM (Melting touch stack molding technology)
- Body structure: Patent technology V-Slot aluminum bearing
- Nozzle diameter: Standard 0.4mm(can be changed to 0.3/0.2mm)
- Filament diameter: 1.75mm
- Plug: Default EU plug
- Print speed: Max.: 200mm / s, Normal: 80mm / s
- Each accuracy: 0.05-0.4mm (adjustable)
- Power supply: Input 110-220V switchable, output 24V
- Actual power: 160-200W
- Printing accuracy: ±0.1mm
- Environmental requirement: 10-30°C, humidity 20-50%
- Filament materials: PLA, ABS, TPU, Copper, Wood, Carbon Fiber, Gradient Color etc.
- Software supporting: PROE, Solid-works, UG, 3d Max, Rhino 3D design software, etc.
- Format: STL, OBJ, G-Code, JPG
- Printing method: SD card(off-line), contact to the PC(on-line)
- Operating system: Linux, Windows, OSX
- Operating software: CURA, Repetier-Host, simplify 3D
- Machine size: 490*600*615 mm
- Package size: 540*640*310 mm
- Machine net weight: 10.3kg
- Package weight: 14kg
Out of stock
Creality 3D CR-10S DIY 3D Printer Kit 300*300*400mm designed extremely innovative design, with integrating classic elements, create a new generation economic DIY 3D printers. This is the upgraded version of CR-10 capable of providing more consistent, good-quality prints. Using a Filament detector, can reduce accidents and avoid model printing interrupts. Hence offers a super printing size, thereby saves space but building the world. It provides a spacious print area of 300* 300*400 mm with a controllable heat bed. This helps to print large items or many small items. This 3D printer with Dual lead screws with motor offers high durability, and long-lasting. Using the Industrial-grade PCB mainboard, more highly integrated modules, can be continuously print for about 200 hours without pressure. Thus provides output with matures printing technology and stable performance.
This easy to install and high-performance printer offers many filament options beyond common plastics like PLA, ABS, TPU, Copper, Wood, Carbon Fiber, Gradient Color, etc. This 3D Printer kit features a Patent MK10 nozzle extrusion structure that effectively reduces the risk of plugging and poor spillage. Thus can print more printing material without block. The newest V- slot linear bearing system offers high accuracy, and excellent dimensional stability helping to reduce noise levels greatly.
This 3D printer features aviation grade fast connector and requires only 10 minutes to the assembly before the first printing. This simple assembly but more stable performance. Moreover, the Electronic control host was separated from the printing body, in order to meet the needs of refitting printing size to various specifications according to your imagination.

Related products
12V 40W Ceramic Cartridge Heater 6mm*20mm For Extruder 3D Printers
- Material: stainless steel,
- Core: ceramic.
- Voltage: 12V.
- Power: 40W.
- Diameter: 6mm, Heating Length: 20 mm.
- Wire Length: 100 cm.
- Works on many 3D printers, including RepRap and Prusa models.
- It fits nicely in our extruder, so it’s an easy replacement.
- Small but powerful.
- Get your hotend hot quickly.
- This unit is a more powerful unit than the standard unit for many 3D printers.
Arduino CNC Shield v3 Engraving Machine/3D Printer/A4988 driver GRBL compatible
- Coolant enable
- Uses removable Pololu A4988 compatible stepper drivers. (A4988, DRV8825, and others) (Not Included)
- Jumpers to set the Micro-Stepping for the stepper drivers. (Some drivers like the DRV8825 can do up to 1/32 micro-stepping )
- Compact design.
- Stepper Motors can be connected with 4 pin Molex connectors or soldered in place.
- Runs on 12-36V DC. (At the moment only the Pololu DRV8825 drivers can handle up to 36V so please consider the operation voltage when powering the board.)
- Please note that this is an unassembled kit and needs soldering.
- Latest Arduino CNC Shield Version 3.10
- GRBL 0.9 compatible. (Open source firmware that runs on an Arduino UNO that turns G-code commands into stepper signals)
- PWM Spindle and direction pins
- 4-Axis support (X, Y, Z, A-Can duplicate X, Y, Z or do a full 4th axis with custom firmware using pins D12 and D13)
- 2 x End stops for each axis (6 in total)
MACH3 interface board
- Compatible Stepper Motor Driver - Max 5 2-phase Microstep controllers
- Driver type - Pulse and Direction signal control
- Wide input voltage range: 12-24V, and with anti-reverse function.
- Output 0-10V analogue voltage for the inverter to control the spindle speed.
- Compatible with MACH3, Linux CNC (EMC2) etc. parallel-control CNC software.
- USB power supply and peripherals power phase are separate to protect computer security.
- All the signals are to-isolate which can protect your computer security.
- 5-input interface to define the Limit, Emergence-Stop, Cutter alignment, etc.
- Wide input voltage range: 12-24V, and with anti-reverse function.
- One relay output control interface, accessed by the spindle motor or the air pump, water pump, etc.
- Maximum support 5-axis stepper motor driver controllers
- Output 0-10V analogue voltage for the inverter to control the spindle speed.
- All the way to the relay output port, control spindle switch. Output port P17 mouth.
- One relay output control interface, accessed by the spindle motor or the air pump, water pump, etc.
- Weight - Approx. 75g
- Dimensions - 90 * 70 * 20mm
NEMA 23 10.1 kg-cm
- Operating Voltage : 2.3 Volts
- Step Angle : 1.8°
- Holding Torque : 10.1 kg-cm
- Supply Current (A) : 2.8 Ampere/Phase
- Number of Leads : 4
- Inductance : 2.2 mH/Phase
- Resistance : 0.83 Ohm
- Rotor Inertia : 275 gm-cm2
- Weight (gm) : 650
- Detent Torque (kg-cm) : 0.36
- Frame Size (mm) : 57 x 57
- Inductance Accuracy : ±20%
- Resistance Accuracy : ±10%
- Shaft Diameter (mm) : 6.35
- Shaft Length (mm) : 20.6
- Step Angle Accuracy : ±5%
- Comparably more powerful than NEMA17 motors.
- The input pulse decides the rotation angle of the motor.
- High accuracy of around 3 to 5% a step.
- It provides good starting, stopping, and reversing.
- Control of this motor is less costly because of the exclusion of complex control circuitry.
- The speed is proportional to the frequency of the input pulses.
NEMA 23 18.9 kg-cm
- Step Angle : 1.8 °
- Holding Torque : 18.9 kg-cm
- Operating Voltage : 3.2 Volts
- Supply Current (A) : 2.8 A/Phase
- No. of Leads : 4
- Inductance: 3.6 mH/Phase
- Resistance : 1.13 O/Phase
- Rotor Inertia : 480 gm-cm2
- Inductance Accuracy : ±20%
- Resistance Accuracy : ±10%
- Shaft Diameter (mm) : 6.35
- Shaft Length (mm) : 20.6
- Cable Length: 30 CM
- Comparably more powerful than NEMA17 motors.
- Input pulse decides the rotation angle of the motor.
- High accuracy of around 3 to 5% a step.
- Provides good starting, stopping and reversing.
- Control of this motor is less costly because of exclusion of complex control circuitry.
- The speed is proportional to the frequency of the input pulses.
PR34 2004 LCD Display Smart Controller W or Adapter for RAMPS1.4 Reprap 3D Printer
- RAMPS 1.4 2004 LCD Display intelligent controller.
- LED background light control circuit, a small function of the intelligent controller,
- With pin short time to decide on all LED turn or steering 30 seconds
- You can turn on the light time to do the long or short form of the adjustment TRIMM R4100K from 10 seconds to 2 minutes.
- Plug and play on the RAMPS, but need to modify the firmware to support.
- The product comes encoder parameter adjustment can be achieved, and the file selection print.
- With an SD card base on the back, put slicing file into the SD card and select the file on the LCD, then can be printing.
Ramps 1.6 For 3D Printer Parts
- Input voltage: 12V.
- Power: 200W.
- Patch MOS tube: B55NF06.
- Ramps 1.6 is a 4-layer board.
- Can be extended to LCD and other parts.
- There are heater and fan MOSFET outputs and 3 thermistor interfaces
- Support motor drivers: support A4988 DRV8825 and other motor drivers(support five motor drivers Simultaneously).
- 5A additional security and component protection fusion.
- Heated bed controls additional 11A fuses.
- Applied to 5 Pololu stepper drive board.
- Design of Pololu plate pin socket can be easily replaced or removed for future design.
- I2C and SPI pins are available for future expansion.
- Servo connectors are used for connecting limit stops, motors and light-emitting diodes.
- LED will light when the heater has output, choose 2 motors to connect to Z Prusa Mendel.
- Dimension: 101.5 * 60.5mm
