HLK-RM04 UART to Serial Wifi Ethernet Wifi Module
Original price was: ₹890.00.₹750.00Current price is: ₹750.00. inc. GST
GPS Modem SKG13C External Antenna
Original price was: ₹2,500.00.₹2,000.00Current price is: ₹2,000.00. inc. GST
- Operating voltage: 3.0V to 4.2V
- Ultra high sensitivity: -165dBm
- Extremely fast TTFF (Time To First Fix) at the low signal level
- Low power consumption: Typical 45mA@3.3V
- NMEA-0183 compliant protocol or custom protocol
- Operating temperature range: -40 to 85℃
- SMD type with stamp holes
- Small form factor: 15x13x2.7mm
- RoHS compliant (Lead-free)
- Support walk model
Description
The SkyNav SKG13C designed as a complete GPS engine module. It features super sensitivity, ultra-low power, and a small form factor. This GPS Receiver SKG13C designed with an External Active Antenna is quite easy to use with PC or MCU.
The GPS signal applied to the antenna input of the module. It consists of a complete serial data message with position, velocity, and time information presented at the serial interface with NMEA protocol or custom protocol. Thus GPS Modem SKG13C offers high-performance features of the MediaTek 3329 single-chip architecture. Due to the high tracking sensitivity of  –165dBm, the module helps to extend positioning coverage into urban areas and dense foliage environments where the GPS was unable to reach before. Moreover, the small form factor and low power consumption make the module installation quite easier and simpler. Thus it can be easily integrated into portable devices like PNDs, mobile phones, cameras, and vehicle navigation systems. Moreover, it supports Dual Power Source, Serial, and TTL output Free GPS Active Antenna.
Applications
- LBS (Location-Based Service)
- PND (Portable Navigation Device)
- Vehicle navigation system
- Mobile phone
