Showing all 4 results

7417N Hex Buffer Driver IC

35.00 inc. GST
  • Hex Buffer/Driver
  • High-level output voltage: 15V
  • Low-level output voltage: 0.7V
  • High-level output current: 0.25mA
  • Low-level output current: 40mA
  • Input clamp voltage: -1.2V
  • Propagation delay time max.: 30ns
  • Supply voltage range: 4.75 to 5.25V
  • Package: DIP-14

74LS47 BCD to Seven Segment Decoder Driver IC

35.00 inc. GST
  • BCD to Seven Segment Decoder/Driver
  • High-level input voltage: 2V
  • Low-level input voltage: 0.8V
  • High-level output current: -50µA
  • Low-level output current: 3.2mA
  • No. of inputs: 4
  • No. of outputs: 7
  • Propagation delay time: 100ns
  • Supply voltage range: 4.75 to 5.25V
  • Package: DIP-16

CD4054 4 Segment Liquid Crystal Display Driver IC

25.00 inc. GST
  • 4 Segment Liquid Crystal Display Driver With Strobed Latch Function
  • Supply Voltage Range: 3 to 20V
  • Input Current: ±10mA
  • Power Dissipation: 200mW
  • Low level Output Voltage: 0.05V
  • High level Output Voltage Min.: 4.95V
  • Low level Input Voltage Max.: 1.5V
  • High level Input Voltage Min.: 3.5V
  • Propagation Delay Time Max.: 800ns
  • Package: DIP-16

IRS2110 High and Low Side Driver IC

  • High Side Floating Supply Voltage Max.: 520V
  • Logic 1 input voltage Min.: 9.5V
  • Logic 0 input voltage Max.: 6V
  • High level output voltage Max.: 1.2V
  • Low level output voltage Max.: 0.15V
  • Total Power Dissipation: 1.6W
  • Propagation delay Max.: 160ns
  • Rise Time Max.: 35ns
  • Fall Time Max.: 25ns
  • Package: DIP-14
