Black 2M Usb 6 Led Waterproof Borescope Endoscope Inspection Tube Camera
₹3,500.00 Original price was: ₹3,500.00.₹3,000.00Current price is: ₹3,000.00. inc. GST
- USB interface: USB 2.0
- Cable Length: 2M
- Camera head outer diameter: 7mm.
- Pixels: 300000 pixels.
- Resolution: 640*480(VGA), 30 ftps.
- LED: 6 white LED bright light.
- Focal distance: 2cm-infinate.
- Waterproof level: IP67.
- Temperture: -20 ~ 100℃.
- Color: black
Out of stock
The Black 2M USB 6 Led Waterproof Borescope Endoscope Inspection Tube Camera has become a must-have accessory for tradesmen, medical professionals, and DIYers. They are now essential tools for mechanics and car enthusiasts even in the medical field. This is an endoscope camera with 0.3megapixel 640 x 480 resolution 7mm lens camera which provides high-definition images. This Small size, lightweight, front-end camera is designed with a housing diameter of 7mm. The 6 tiny white LEDs on the module help to see those dark places you want to look into. Hence LED lights can be turned on or off, which will not affect the normal work of the endoscope.
This Mini USB Inspection Camera is designed based on optoelectronic technology to investigate hard-to-reach areas. This inspection camera offers a wide range of applications including ear detection, oral examination, search and rescue, pipeline inspection, engine inspection, video monitor, sewer pipe inspection, cast mold inwall inspection, etc. It also offers high-resolution pictures or videos with a 1/9 camera featuring a waterproof wire endoscope.
Thus it captures pictures records videos and saves videos on your computers which is very convenient for follow-up analysis. Therefore, the captured images/videos are transmitted digitally or displayed via Wi-Fi, Bluetooth, or USB connector. The USB interface supports computer plug and plays easy installation. This USB endoscope is a portable, handheld video endoscope system with a flexible insertion tube. Moreover, this Endoscope is designed with a small hook, magnet, and side audition. This makes it easier to take out the small objects in the gap and is favourable for daily maintenance work. The module consists of a 2-meter long cable featuring IP67 waterproof and dustproof cable. This makes it ideal for underwater viewing.
