2000W SCR voltage regulator designed to manage 220V appliances as a high-power electronic SCR dimmer. The potentiometer knob may regulate the speed, voltage, and temperature of the appliances by connecting the input to the module and the output to the appliances in series. This is a straightforward and straightforward module that regulates appliances up to 2000W. The voltage regulator’s long life is ensured by the peak voltage absorption circuit, which protects the high-power thyristor. With a 2-way high-power silicon controlled potentiometer and nuts, they are extremely visible and convenient gadgets. As a result, no external components are required. SCR Voltage Regulator is commonly found in light dimmers, fan speed controllers, stove temperature controllers, electric furnaces, and other similar devices.
With a maximum power of 2000w, this Voltage Regulator has reverse polarity protection, high current protection, and a high-temperature fr-4 circuit board. Furthermore, the use of a novel two-way high-power thyristor enables the mains current to be adjusted up to 25 A. In the case of cooling, it also eliminates the over-current problem caused by the heating wire resistance being too low. As a result, the output voltage may be changed between 90 and 220 volts for use with electrical equipment such an electric stove, a water heater tuned thermal, a lighting dimmer, a small motor speed, and an electric iron thermostat. To accomplish the impact of dimming, thermostats, and pressure regulators.
SCRs are mostly used in devices that need the control of high power, perhaps incorporating high voltage. They may also be utilised in medium- to high-voltage AC power management applications, such as light dimming, power regulators, and control, due to their functioning.
