Pic Kit-2 Programmer
₹2,400.00 Original price was: ₹2,400.00.₹2,200.00Current price is: ₹2,200.00. inc. GST
- Supported Device Families: PIC10F,PIC112F, PIC16F,PIC18F,PIC24
- Programs all current 8-, 16-, and 32-bit Flash PIC microcontrollers.
- Includes the UART Tool and Logic Tool microcontroller development utilities.
- With a portable USB power source, PICkit 2 will program the downloaded code into a PIC Microcontroller
- High-quality PCB FR4 Grade with FPT Certified
The PICkit 2 Development Programmer/Debugger was designed as a low-cost development tool with an easy-to-use interface for programming and debugging Microchip’s Flash families of microcontrollers. This programmer is capable of programming all current 8-, 16-, and 32-bit Flash PIC microcontrollers. And also includes the UART Tool and Logic Tool microcontroller development utilities.
Microchip’s PICKit2 is designed as much more comfortable, reliable, and powerful than the other programmers all over the internet. It is a USB-based ICSP (In-Circuit Serial Programming) programmer. As PICKit2 is a USB-powered device, it gets power from a PC USB +5V power supply. Meanwhile, the soul of the PICKit2 is the USB microcontroller PIC18F2550. The USB Data+ and Data- from the PC connected to the D+ and D- pins of the PIC182550. Moreover, using a portable USB power source, PICkit 2 will program the downloaded code into a PIC Microcontroller. It is made up of high-quality PCB FR4 Grade with FPT Certified. This programmer module supports the following device families:
- PIC10F
- PIC12F
- PIC16F
- PIC18F
- PIC24
