Power Line Carrier Module KQ-430F
₹2,000.00 Original price was: ₹2,000.00.₹1,500.00Current price is: ₹1,500.00. inc. GST
- Power: DC +5V
- Working rate:120~135KHZ
- Interface baud rate:9600bps, the true baud rate is 100bps,250-byte buffer
- Temperature:-25 degree~+70 degree
- Humidity: 90%
- Receiver:11mA Transmitter:300mA
Category: Modules
Tags: Carrier, KQ-430F, Power Line, Power Line Carrier Module, Power Line Carrier Module KQ-430F
Description
This is Power Line Carrier Module KQ-430F used for communication over Power Line. This module communicates between two devices through a Power line (e.g 220V power line) without any extra components.
Pin configuration:
- 1P-AC: The voltage of the fire line is 220V AC (or zero line)
- 2P-AC: 220V alternating current voltage zero line (or FireWire)
- 3P-+5V: +5V to transfer power (210mA), single income data can be empty to decrease power consumption
- The 4P-GND stands for digital circuit ground.
- 5P-+5 V: +5 V operational supply 11mA, lowest working voltage 3.3V, but not recommended
- TTL level, carrier data enters, then MCU TXD 6P-RX
- TTL level, carrier data out, then the microcontroller 7P-TX RDX
- 8P-MODE: mode selection is low, whether the mode is unoccupied or coupled to a 5V high ground.
- 9P-NC/RST: reset pin (active low) switching mode. This feature is unnecessary; the pin should be removed.
- The interface baud rate is 9600bps, while the true baud rate is 100bps, with a 250-byte buffer.
- Receiver:11mA Transmitter:300mA
