The Sensor Shield V5 Expansion Board For Arduino is the latest shield compatible with Arduino Uno and Arduino Due. This latest Sensor Shield V5 Expansion Board For Arduino is generated by a robot. Designed to retain the advantages of version V4.0 on the basis of stack design, PCB Immersion Gold processing technology. This shield features newly added many kinds of interface, for example, IIC interface, 32 channels servo motor interface, Bluetooth communication module interface, SD Card communication module interface and so on, more convenient.
Each functional module consists of a buckled port with VCC, GND, and Output. Which has the corresponding port on the Sensor Shield, connected with a plain 2.54mm dual-female cable. These Buckled brick cables are like cement for bricks. It makes the connections easier, secure, and more professional looking.
Using this expansion board, we can easily connect the usual analogue sensors such as ray sensors. You can use this expansion board and the corresponding circuit module, by just combining Arduino and sensors module using special cables. This is because concrete circuit details achieve by the corresponding sensors module. So you only need to consider that how to read data coming from the sensor by the program in Arduino.
This sensor shield is the perfect choice for Arduino beginners. As you do not have a headache for the cumbersome and complex circuit connection. A sensor requires only a common 3P sensor cable (regardless of digital cable and analogue cable), which can easily connect to the board simplifying the circuit. Soon after the completion of the circuit, the corresponding Arduino program was downloaded to the Arduino Duemilanove controller. Hence reads the sensor data, or receives a wireless module to return data after computing the final easy-to-complete your own interactive works.
This module is compatible with the following Arduino Boards:-
- Arduino UNO
- Arduino DUE
