The New Arduino Mega R3 Sensor Shield V2.0  is the latest shield compatible with Arduino mega(1280) or Arduino mega (2560) or Arduino mega(ADK) without the use of the breadboard.  This Sensor Shield board has the advantages of PCB Immersion Gold processing technology, all of the digital and analogue interfaces. And it also expands the mega with Bluetooth module communication interface, SD card module communication interface, APC220 radio-frequency module communication interface, RB URF v1.1 ultrasonic sensor interface, and ICSP interface easy to use for extension.
Each functional module consists of a buckled port with VCC, GND, and Output. Which has the corresponding port on the Sensor Shield, connected with a plain 2.54mm dual-female cable. These Buckled brick cables are like cement for bricks. It makes the connections easier, secure, and more professional looking.
Using this expansion board, we can easily connect the usual analogue sensors such as ray sensors. You can use this expansion board and the corresponding circuit module, by just combining Arduino and sensors module using special cables. This is because concrete circuit details achieve by the corresponding sensors module. So you only need to consider that how to read data coming from the sensor by the program in Arduino.
This sensor shield is the perfect choice for Arduino beginners. As you do not have a headache for the cumbersome and complex circuit connection. A sensor requires only a common 3P sensor cable (regardless of digital cable and analogue cable). This can easily connect to the board simplifying the circuit. Soon after the completion of the circuit, the corresponding Arduino program was downloaded to the Arduino mega controller. Hence reads the sensor data, or receives a wireless module to return data after computing the final easy-to-complete your own interactive works.
