In most of the Arduino projects, it would be extremely delighted to have a display through which we can monitor the vitals of our project. 1.8 Inch TFT LCD Touch Screen for Arduino display module designed specifically for Arduino compatible MCU Board. This module adds a touch up to your Arduino project with a beautiful large touchscreen display shield with a built-in microSD card connection. The display can load images from an SD card using the SD card slot present at the back of the device.
This 1.8 Inch TFT LCD designed with a ST7735 coloured TFT display with a resistive touch screen. The ST7735TFT display provides a resolution of 120×160 pixels which can display a wide range of colours ( full 18-bit colour, 262,144 shades!). Thus providing a better display. It offers more resolution than a black and white 128×64 display. This 1.8 Inch TFT LCD Screen display has an ST7735 controller IC which supports MCU Interface. It is well known for their low cost and small size structure. The ST7735 TFT uses SPI (serial peripheral interface) protocol to communicate with the master device
The display uses the SPI protocol for communication and has its own pixel-addressable frame buffer. Which means often used with all kinds of microcontroller and we just only need 4 I/O pins. To enrich the display, it also comes with an SD card slot on which colored bitmaps often loaded and easily displayed on the screen.
PIN DESCRIPTION:
- RST: reset
- CS : chip select
- D/C: data/command
- DIN: data in
- CLK: clock
- VCC: Power Supply
- BL: backlight
- GND: Ground
