CA-3110 Dual Channel Stereo Class Amplifier Board

CA-3110 Dual Channel Stereo Class Amplifier Board Module is an 8-18V single Onboard TPA3110D2 stereo audio amplifier chip. This Dual Channel Stereo Class Amplifier Board is designed as a 15W (per channel)Class-D audio power amplifier for driving bridged-tied stereo speakers. The Stereo Amplifier operates at a voltage range of 8V to 18V supply at a much higher efficiency than other prominent ICs.The Onboard TPA3110D2 audio power amplifier chip supports double-track 15W + 15W, which is suitable for 4/8 impedance to drive 15-45W speakers.

CA-3110 Dual Channel Stereo Class Amplifier Board features a short-circuit protection system with an arrangement for automatically limiting the dissipated power. This keeps the operating point of the output transistors within their safe operating range. TPA3110D2 audio amplifier module has a wide range of applications in-car stereo receivers, tape recorders, medium-power audio equipment, etc.

Low THD + N(0.1%) indicates a very low noise power amplifier, that can be easily fitted in any musical amplifier-related project. Moreover, It does not require a heatsink, thereby saving additional board space. Apart from the heatsink, it also provides thermal protection features which is another essential function for such a small wattage amplifier module. This simple TPA3110D2-based Power Supply Audio amplifier board module directly connects the input from your instrument to the speaker. Thus the module output connects to the single output speaker.
