Ceiling-mounted PIR motion sensor
Technical Specifications – PIR Motion Sensor (Ceiling Mounted)
| Parameter | Specification |
|---|---|
| Product Type | PIR Motion Sensor |
| Mounting Type | Ceiling Mounted |
| Detection Angle | 360° |
| Detection Range | Up to 6–8 meters |
| Detection Speed | 0.6 – 1.5 m/s |
| Operating Voltage | AC 220–240V, 50/60Hz |
| Load Capacity | ≤1200W (Incandescent) / ≤300W (LED) |
| Time Delay | Adjustable: 10 seconds – 7 minutes |
| Light Sensitivity | Adjustable: <3 – 2000 LUX |
| Sensor Technology | Passive Infrared (PIR) |
| Installation Height | 2.2 – 4 meters |
| Operating Temperature | –20°C to +40°C |
| Power Consumption | <0.5W |
| Housing Material | ABS Plastic |
| Color | White |
| IP Rating | IP20 (Indoor Use) |
| Application Area | Indoor |
| Certifications | CE / RoHS (Model dependent) |
Description
This ceiling-mounted PIR motion sensor is designed for smart and automatic lighting control in homes, offices, and commercial spaces. With 360-degree motion detection, it accurately senses human movement and activates connected lights or appliances only when needed. Ideal for corridors, restrooms, parking areas, staircases, and conference rooms, this sensor helps improve convenience while significantly reducing power consumption.
Key Features
-
Detection Angle: 360°
-
Installation: Ceiling Mount
-
Detection Distance: Up to 6–8 meters (approx.)
-
Adjustable Time Delay: 10 seconds to 7 minutes
-
Adjustable Light Sensitivity (LUX control)
-
Compatible with LED, CFL, and incandescent lights
-
Compact, durable ABS housing
Applications
-
Homes & Apartments
-
Offices & Conference Rooms
-
Staircases & Corridors
-
Parking Areas
-
Washrooms & Public Spaces
-
Smart Building Automation Systems
