PIR Motion Sensor Module with Portable Wire
Specifications
-
Sensor Type: Passive Infrared (PIR)
-
Detection Distance: Up to 6–7 meters
-
Detection Angle: ~120°
-
Operating Voltage: 5V DC
-
Output Type: Digital (High/Low)
-
Wire Type: Portable pre-attached cable
-
Operating Temperature: -20°C to +60°C
Applications
-
Motion-activated lights
-
Security & alarm systems
-
Smart home automation
-
Arduino & Raspberry Pi projects
-
Robotics & IoT development
Description
This PIR Motion Sensor with Portable Wire is designed to accurately detect human movement by sensing infrared radiation emitted by the body. With a ready-to-use portable wire, it ensures fast installation and hassle-free integration into your electronics projects.
The sensor offers stable performance, low power consumption, and reliable output, making it ideal for home automation, security systems, smart lighting, robotics, and IoT applications. Whether you’re a student, hobbyist, or professional developer, this PIR motion sensor delivers consistent and dependable results.
Key FeaturesÂ
-
Accurate Motion Detection: High-sensitivity PIR sensor detects human movement using infrared heat signatures
-
Plug & Play with Portable Wire: Pre-attached portable wire enables easy and quick connection without soldering
-
Wide Detection Range: Detects motion up to 6–7 meters with adjustable sensitivity
-
Low Power Consumption: Energy-efficient design suitable for battery-powered and IoT applications
-
Versatile Applications: Perfect for smart lighting, security alarms, robotics, Arduino, Raspberry Pi, and DIY projects
