Vibrator Motor Button Type
Original price was: ₹60.00.₹50.00Current price is: ₹50.00. inc. GST
Attiny 5 Version 1
Original price was: ₹300.00.₹250.00Current price is: ₹250.00. inc. GST
Micro DC 3-6V Submersible Pump Mini water pump
Original price was: ₹180.00.₹150.00Current price is: ₹150.00. inc. GST
- Operating Voltage : 3 ~ 6V
- Operating Current : 130 ~ 220mA
- Flow Rate : 80 ~ 120 L/H
- Maximum Lift : 40 ~ 110 mm
- Continuous Working Life: 500 hours
- Driving Mode: DC, Magnetic Driving
- Material: Engineering Plastic
- Outlet Outside Diameter: 7.5 mm
- Outlet Inside Diameter : 5 mm
Description
Micro DC 3-6V Submersible Pump Mini water pump is a low-cost and lightweight water pump. It is ideal for submersible pumps for a variety of liquid and air movement applications. As it provides enough pressure, used with nozzles to make the spray systems. This submersible mini water pump is highly resistant to heat. It operates at a voltage range of 3 ~ 6V power supply. It can take up to 120 liters per hour with a very low current consumption of 220mA. Â By simply connecting tube pipe to the motor outlet, submerge it in water and power it. It should be noted that the water level is always higher than the motor. In case of dry run, damage the motor due to heating and it will also produce noise.
Under the powered condition, the pump can suck water through the tube up to a maximum lift of 40-110cm. This pump runs very quietly with a sound level under 30db while pumping the liquid. Whereas it is also capable of pumping air, but pumping air is quite noisy compared with the liquid.
APPLICATIONS
- Small aquariums pumps
- Automatic plant watering systems
- Water priming pumps
- Music activated dancing water system, etc.
