The Micro MinimOSD is defined as the next evolution of minimization. The Micro Minim OSD performs similar to the very popular Witespy KV Team modded OSD with all features but in a 16x16mm compact size. This module features the absence of a DC/DC converter indicates that less heat is required when powered off a flight controller. The Micro MinimOSD is similar to that of the older MinimOSD hardware. But the updated version took the advantage of custom firmware options. Based on the user requirement, we can choose firmware that is MAVLink compatible for ArduCopter. Or MultiWii Serial compatible for MultiWii and Baseflight / Cleanflight control boards.
It is capable of connecting two batteries up to 4S so that the main flight battery voltage can be seen. The second port on the module will allow FPV battery voltage on the display as well. The MinimOSD is designed specifically for users to provide a powerful OSD at an unreal cost. The onboard pad for analogue or digital PWM RSSI and a connection are established where you can attach a current sensor.
It is perfect for use with ArduPilot Mega and the MAVlink protocol and designed to be as compact as possible. This module consists of an ATmega328P 8 bit microcontroller as its main part with an Arduino bootloader. A MAX7456 monochrome on-screen display indicates the status of the flight controller. Finally, Programming is done through an FTDI card. This Board can be simply used as a normal OSD for APM or it can be used with MWC KV Team Mod.
