The LED bar designed based on an LED array with 10 segments of LEDs in one package. This LED bar device features a compact size and an easy interface. Each led in this array designed with different pins and hence controlled separately. This is used to make a small linear display with a glowing red color using this elegant LED bar graph.
These 10 segment bar graph LEDs offer numerous advantages. Due to their compact footprint, simple hookup, they are easy for prototyping or finished products.
Generally, these 10 individual blue LEDs combined together, each with an individual anode and cathode connection. This module supports segment colors such as 2 red, 3 yellow, 4 green,1 blue. There are 20 pins, 10 on each side, with 0.1″ spacing hence can easily plug it into a breadboard with plenty of space for wiring left over. This display with 10 LEDs encapsulated in a plastic body which is bright, beautiful, and funky with nice diffused rectangular lenses for a striking look. These modules are ideal for audio and meter displays which is quite economical and easy to install.
- As an indicator for signal strength, audio signal, power status, etc
- Art display and DIY project
- Instrument panel
- Digital readout display
