STC Automatic Programmer USB – TTL 5V 3.3V SCM Burning Programmer

This STC Automatic Programmer USB –TTL 5V 3.3V SCM Burning Programmer is designed as a 5th Generation STC Full Range of Single-chip Microcomputer. This downloader supports the 3.3V and 5V STC series of all the microcontroller programming procedures. And support MSP430 single-chip BSL programming (only with MspFet software). This programmer is capable of supporting the highest baud rate of 115200 perfect support. So that is no longer for the STC12 series, STC11 series, STC15 series of burning distress.

This programmer module does not require frequent power to the microcontroller power. This means that the programmer automatically downloads without a cold start. This feature makes the STC microcontroller download program becomes very convenient, simple, and easy to operate. Moreover, this programmer support 3.3V and 5.0V version of the STC single-chip burner, download the integrated 3.3V power management chip, 3.3 external power supply up to 500MA, from the 3.3V power supply.

The success rate of STC12, STC15, STC11, STC10 series programs can be up to 100%. This programmer uses CH340 + single-chip microcomputer to control the core to kill STC full range of high-speed programming. The motherboard is protected via a 500mA self-healing fuse. The burner motherboard is encapsulated in the metal aluminium shell to protect the burner motherboard from the fear of metal on the desktop thing short your burner. Apart from these Interface definition is printed on the shell. When burning STC SCM, soon after clicking download, the light will turn OFF. The light flashes only when there is data transmission, if no data transmission, it will always keep bright. Finally, this programmer module supports the WIN7 system, compatible with all the subsequent systems, supports a 64-bit system.

STC SCM burning instructions (four pins required):

• 5.0V / 3V3 (SCM VCC)
• TXD (SCM P3.0)
• RXD (SCM P3.1)
• GND (SCM GND)
