TL866II Plus Universal USB MiniPro USB Programmer for 15000+IC SPI Flash NAND EEPROM MCU PIC AVR

This TL866II Plus Universal USB MiniPro USB Programmer for 15000+IC SPI Flash NAND EEPROM MCU PIC AVR may be a well-designed cheap professional programmer. This programmer supported high-density SMD technology, a unified interface. Designed in such a way that easy to use, fully functional, reliable programmer running of application software. This Ultra-small code runs faster and supports bilingual(English and Chinese). Meanwhile, it can automatically identify the OS to put in and run under WIN 2000/WIN XP/WIN 2003/WIN 2008/WIN VISTA /WIN7/WIN8/WIN10 (32-Bit/64-Bit).

This programmer comes with an inbuilt MCU with a high-performance and high-capacity USB interface. It’s operated at the communication speed of 12Mbps being in line with ( for every chip) a well-designed programming algorithm and USB high-speed communications. Hence, TL866II defined as one among the fastest integrated development programmers, in which the speed has been met the requirements of small-quantity efficient production.

The ultra-low-power chips provided by the whole programmer and supplied with electricity via USB Interface. It’s the primary comprehensive programmer to program all the chips without an external power supply. Their own power consumption is a smaller amount than 20mA (it is 7mA when the programmer isn’t programming, LED power indicator use the largest electricity, 5mA each one). And Programming power loss rate is a smaller amount than 20% in order that the programmer can supply the high VCC VPP programming current.

VPP and VCC programming voltages are independently program-controlled: programmable VCC from 1.8V to 6.5V; VPP from 1.8V to 18V. The fluctuation of the power supply is minor due to the multi-stage LC filter. Moreover, this programmer provided with upgrading Function of the built-in hardware firmware program. Thus confirms your programmer’s firmware flash and application software updated timely. This programmer features a sort of automatic numbering functions commonly used. TL866ll Plus programmer programs through the 40-PIN universal socket and given an ICSP serial programming port. Finally, the Original chip encryption operation on the AVR microcontroller performed with an internal RC Calibration byte. The Decrypt software can not be directly run on another same type of chip.

Support a wide range of chips:
15000+ supported devices from hundreds of manufacturers by 7.05 version of SW
NAND FLASH: Samsung K9xxx, SK Hynix (ex Hynix) HY27xxx, H27xxx, Micron MT29Fxxx, NANDxxx, Spansion S34xxx, NAND Toshiba TH58NVGxxx.

Serial NAND FLASH: Micron MT29Fxxx.
Serial Flash: standard SPI, high performance Dual I/O SPI and Quad I/O SPI (25Bxxx, 25Dxxx, 25Fxxx, 25Lxxx, 25Pxxx, 25Qxxx, 25Sxxx, 25Txxx, 25Uxxx, 25Vxxx, 25Wxxx, 25Xxxx, 26Vxxx, 45PExx, MX26Lxxx ).DataFlash (AT45Dxxx, AT26Dxxx)
Parallel NOR Flash: 28Fxxx, 29Cxxx, 29Fxxx, 29BVxxx, 29LVxxx, 29Wxxx, 49Fxxx series, Samsung’sK8Pxxxx, K8Dxxxx series, …
EPROM: NMOS/CMOS, 27xxx and 27Cxxx series
EEPROM: NMOS/CMOS, 28xxx, 28Cxxx, 27EExxx series,
Serial E(E)PROM: 24XXX,25XXX series,
Microcontrollers MCS51 series:89Cxxx, 89Sxxx, 89EXXX,89VXX
Microcontrollers Atmel AVR 8bit/16bit: AT90Sxxxx, ATtiny, ATmega series
Microcontrollers Microchip PICmicro: PIC10xxx, PIC12xxx, PIC16xxx, PIC17Cxxx, PIC18xxx, PIC24xxx series

GAL Programmable logic device programming and SRAM test:
I.C. Tester: TTL type: 54,74 S/LS/ALS/H/HC/HCT series; CMOS type: 4000, 4500 series;
Static RAM: 6116 …
