IN4007 Diode
4 Pin RMC Connector
40V Metal Oxide Varistor (MOV)
4.7uf 63V Caps DC Electrolytic Capacitor
TOP258PN Off-line Switcher IC
4 Pole 2 Way DPDT 12pin ON OFF Switch
UF4007 Diode
- Maximum Recurrent Peak Reverse Voltage - 1000 V
- Maximum Average Forward Output Current - 1 A
- Maximum Forward Voltage Drop per element at 1.0A DC - 1.7 V
- Maximum reverse recovery time - 75 ns
- Typical Junction Capacitance 15 pF
- Package - DO-41
- Operating and Storage Temperature Range: -55...+125 °C
- Weight 0.33 grams
PT2258 6-Channel Electronic Volume Controller IC
- CMOS Technology
- Low Power Consumption
- Least External Components
- Attenuation Range: 0 to -79dB at 1dB/step
- Operating Voltage: 5 to 9 V
- Â Low Noise, S/N Ratio>100dB (A-weighting)
- Â High Channel Separation
- I2C Bus Control Interface
- Selectable Address
- 6-Channel Outputs
- Â Available in 20 pins, DIP or SOP
3.9nf 2000V DC Box Capacitor
- Capacitance: 3.9nf
- Voltage Rating: 2000V
- Dielectric Type: Double Metallized PP
- Capacitance Tolerance: ± 10%
- Capacitor Case Style: Radial Box
- Capacitor Terminals: Radial Leaded
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard
- High Accuracy, Long-Life Polyester Film Capacitor
- Low Leakage
- Easy Mounting
2 Pole 2 Way DPDT 6pin ON OFF Switch
- Used on low voltage or high voltage circuits
- Great for switching lights or motors
- This switch is NOT momentary
- There is no center position
- Rated voltage & current: AC 125V, 6A
- Rated voltage & current: AC 230V, 3A
- Pin number: 6 Pins
- Position: 2 Positions (ON / ON)
- Material: Plastic, Metal
- Size: 13 x 33mm
