LM317K 1.2V to 37V Adjustable Voltage Regulator IC
LM324N Quad Operational Amplifier IC
MOQ: 2 nos
- Low Power Quad Operational Amplifier
- Input Offset Voltage (max): 7mV
- Input Offset Current (max): 50nA
- Input Bias Current (max): 250nA
- Operating temperature (max): 700C
- Output Current (max): 2mA
- CMRR (min): 65dB
- Eliminates Need for Dual Supplies
- Four Internally Compensated Op Amps in a Single Package
- Allows Direct Sensing Near GND and VOUT also Goes to GND
- Compatible With All Forms of Logic
- Power Drain Suitable for Battery Operation
- In the Linear Mode the Input Common-Mode, Voltage Range Includes Ground and the Output Voltage
- Can Swing to Ground, Even Though Operated from Only a Single Power Supply Voltage
- Unity Gain Cross Frequency is Temperature Compensated
- Input Bias Current is Also Temperature Compensated
LM337 3-Terminal 1.5A Negative Adjustable Regulator IC
LM350T 3A Positive Adjustable Voltage Regulator IC
LM393 Low Power Dual Voltage Comparator IC
LM4250 Programmable Operational Amplifier IC
- Input Offset Voltage (max): 6mV
- Input Offset Current (max): 20nA
- Input Bias Current (max): 75nA
- Operating temperature (max): 700C
- Output Current (max): 0.1mA
- CMRR (min): 70dB
- Programmable Operational Amplifier
- ±1V to ±18V power supply operation
- 3 nA input offset current
- Standby power consumption as low as 500 nW
- No frequency compensation required
LM723 Precision Voltage Regulator IC
LM747 Dual Operational Amplifier IC
- Dual General-Purpose Operational Amplifier
- Differential Input Voltage: ±30V
- Input Offset Voltage Max: 6mV
- Input Offset Current Max: 200nA
- Input Bias Current Max: 500nA
- Common-Mode Rejection Ratio: 90dB
- Max. Power Dissipation(each amplifier): 85mW
- Rise Time: 0.3µs
- No frequency compensation required
- Short-circuit protection
- Wide common-mode and differential voltage ranges
- Low power consumption
- No latch-up
- Balanced offset null
- Package: DIP-14
LM7808 8V Positive Voltage Regulator IC
- Output current in excess of 1A
- Internal thermal overload protection
- No external components required
- Output transistor safe area protection
- Internal short circuit current limit
- Available in the aluminum TO-3 package
- Output Voltage: 8V
- Line Regulation (max): 160mV
- Load Regulation (max): 160mV
- Dropout Voltage: 2V
- Output Resistance: 16mΩ
LNK304PN Off-line Switcher IC
- Drain Voltage: -0.3 V to 700 V
- Peak Drain Current: 400 mA
- Feedback Voltage: -0.3 V to 9 V
- Feedback Current: 100 mA
- Operating Junction Temperature: -40 °C to 150 °
- Lowest Component Count, Energy-Efficient Off-Line Switcher IC
- Lowest cost and component count buck converter solution
- Fully integrated auto-restart for short-circuit and open loop fault protection – saves external component costs
- 66 kHz operation with accurate current limit – allows low cost off-the-shelf 1 mH inductor for up to 120 mA output current
