Arduino Mega Pro Mini CH340 Development Board

The Mega Pro Embed CH340G / ATmega2560 board was designed based on the ATmega2560 microcontroller. Along with  Built on the Atmel ATmega2560 microcontroller and USB-UART interface chip CH340G. This board is often an excellent solution to urge your final project on the welding prototype board. Therefore the USB-UART adapter CH340. The board is compatible with Arduino Mega 2560  features a compact form factor of 38 x 55mm and superb solution for developing projects supported by ATmega2560.

The Mega Pro Embed functionalities are similar to Mega 2560. albeit it’s an Embed board, it’s solid as stable because of the Mega Board. It uses the first chip, and 16 MHz high-quality quartz resonators are present on the board. The board uses the chip CH340G because the converter is UART-USB. It provides a stable data exchange result once you work on a frequency of 12Mhz (requires the driving force to be installed on the computer).

We can power the board or power the pins through the MicroUSB connector. The transformer (LDO)  handle input voltages from 6V to 9V (peak 18V) DC. The transformer allows to spend to 18V as an input value, however, we don’t recommend exceeding the recommended values aforementioned, since this will cause excessive heat and damage the device
