Arduino Uno SMD is an open-source based on the Microchip ATmega328P SMD Package developed by Arduino. cc. The DIP packaged ATmega is becoming increasingly difficult to get as Atmel shifts more of its production capacity to surface mount ICs. We’ve added an SMD ATmega to the Arduino Uno R3 to keep up with demand. The board is identical to the PTH version of the Uno, but you’ll need some hot air to remove the ATmega. Most users should be unaffected by this modification.
The current version of Arduino Uno comes with a USB interface, 14 digital I/O pins, 6 analog pins, an ICSP header, 16 MHz ceramic resonators, a power jack, and a reset button. And an Atmega328 microcontroller is used to connect with external electronics circuits. Out of 14 I/O ports, 6 pins were used for PWM output. Each pin operates at a voltage of 5V providing a maximum of 50mA. It also supports serial communication using Tx and Rx pins. Although there are many versions of Arduino like Arduino Uno, Arduino Due, Arduino Leonardo, and Arduino Mega, however, most common versions are Arduino Uno and Arduino Mega. For projects related to digital electronics, embedded systems, robotics, or IoT, then using Arduino Uno would be the perfect option.
Moreover, this microcontroller is programmable with the Arduino IDE common to all our boards and runs both online and offline. The USB connection with the PC is necessary to program the board and not just to power it up. Arduino Uno is powered either by a USB cable or by an external 9-volt battery, although it operates at voltages between 7 and 20 volts. The ATmega328 on the board comes preprogrammed with a bootloader. Therefore, allows uploading new code to it without the use of an external hardware programmer.
