UC3843A Current Mode Controller IC
- High Performance Current Mode Controller
- Bias and Drive Voltages: 30V
- Total Power Supply and Zener Current: 30mA
- Output Current: 1A
- Reference Output Voltage: 5V
- Line Regulation Max: 20mV
- Load Regulation Max: 25mV
- Frequency: 52KHz
- Low Level Output Voltage: 0.1V
- High Level Output Voltage: 13.5V
- Startup Threshold Max: 9V
- Package: DIP-8
74LS374 Edge-Triggered D Flip-Flop IC
- Edge-Triggered D Flip-Flop
- High-level input voltage:Â 2V
- Low-level input voltage:Â 0.8V
- High-level output voltage:Â 5.5V
- High-level output current:Â -6.5mA
- Input clamp voltage:Â -1.2V
- Maximum clock frequency:Â 100MHz
- Propagation delay time:Â 18ns
- Supply voltage range:Â 4.75 to 5.25V
- Package:Â DIP-20
CD4042 Quad Clocked D Latch IC
- Quad Clocked D Latch
- Supply Voltage Range:Â 3 to 20V
- Input Current: ±10mA
- Power Dissipation:Â 200mW
- Low level Output Voltage:Â 0.05V
- High level Output Voltage Min.:Â 4.95V
- Low level Input Voltage Max.:Â 1.5V
- High level Input Voltage Min.:Â 3.5V
- Propagation Delay Time Max.:Â 500ns
- Package:Â DIP-16
- High noise immunity 0.45 VDD (typ.)
- Low power TTL compatibility Fan out of 2 driving 74L or 1 driving 74LS
- Clock polarity control
- Fully buffered data inputs
- Q and Q outputs
74LS15 Triple 3-Input AND Gate IC
74LS260 Dual 5-Input NOR Gate IC
- Dual 5-Input NOR Gate
- Logic Family: LS
- Technology Family: TTL
- Min VCC: 4.75V
- VCC (Max): 5.25V
- Number of Gates: 2
- High Level Output Current: - 0.4 mA
- Low Level Output Current: 8 mA
- Number of Lines In/Out: 5 / 1
- Propagation Delay Time: 12 ns at 5 V
- Supply Voltage Range: 4.75V to 5.25V
- Package: DIP14
- Output type: Push-Pull
- Max Speed: (TPD 10-50ns)
- Max Data rate: 70Mbps
- Low Power Requirements
- Standard TTL Switching Voltages
- Operating temperature range: 0°C to 70°C
74LS27 Triple 3-Input NOR Gate IC
- Triple 3-Input NOR Gate
- Max Supply Voltage 7V
- Max Input Voltage 7V
- TTL outputs
- Maximum ESD: 3.5KV
- Typical Rise Time: 15ns
- Typical Fall Time: 15ns
- High-level input voltage: 2V
- Low-level input voltage: 0.8V
- High-level output current: -0.4mA
- Low-level output current: 8mA
- of gates: 3
- of inputs: 9
- of outputs: 3
- Propagation delay time: 18ns
- Package: DIP-14
- Operating voltage range: +4.75V to +5.25V
- Low power consumption
- Operating Free Air Temperature Range 0°C to +70°C
- Storage Temperature Range -65°C to +150°C
CD4001 Quad 2-Input NOR Gate IC
- Quad 2-Input NOR Gate
- Supply Voltage Range:Â 3 to 15V
- Power Dissipation:Â 200mW
- Low level Output Voltage Max.:Â 0.05V
- High level Output Voltage Min.:Â 4.95V
- Low level Input Voltage Max.:Â 1.5V
- High level Input Voltage Min.:Â 3.5V
- Propagation Delay Time Max.:Â 250ns
- Output Drive Current:Â -3.2mA
- Package:Â DIP-14
CD4012 Dual 4 Input NAND Gate IC
- Dual 4 Input NAND Gate:
- Logic Family:Â HCF40
- No Of Gates:Â 2
- No Of Input Lines:Â 4
- No Of Output Lines:Â 1
- Supply Voltage Range:Â 3 to 20V
- Input Current: ±10mA
- High Level Output Current:Â - 2.4 mA
- Low Level Output Current:Â 2.4 mA
- Low level Output Voltage:Â 0.05V
- High level Output Voltage Min.:Â 4.95V
- Low level Input Voltage Max.:Â 1.5V
- High level Input Voltage Min.:Â 3.5V
- Power Dissipation:Â 200mW
- Operating Temperature:Â -55 to +1250C
- Propagation Delay Time Max.:Â 250ns
- Package:Â DIP-14
78L08 8V Positive Voltage Regulator IC
MOQ: 3 nos
- Output Voltage: 8V
- Input Voltage Regulation: 42mV
- Output Voltage Regulation: 18mV
- Ripple Rejection: 46dB
- Dropout Voltage: 1.7V
- Package: TO-92
- 3-Terminal Regulators
- Output Current up to 100 mA
- No External Components
- Internal Thermal-Overload Protection
- Internal Short-Circuit
- Current Limiting
- Direct Replacements for Fairchild µA78L0
CD4052 Dual 4 Channel Analog Multiplexer or Demultiplexer IC
SEMICONDUCTOR MC74HC4053
- Fast Switching and Propagation Speeds
- Low Crosstalk Between Switches
- Diode Protection on All Inputs/Outputs
- Analog Power Supply Range (VCC – VEE): 0 to 12.0 V
- Digital (Control) Power Supply Range (VCC – GND): 0 to 6.0 V
- Improved Linearity and Lower ON Resistance Than Metal–Gate counter parts
- Low noise
- Chip complexity: HC4053 — 156 FETs or 39 Equivalent Gates
