CM100DU-12H MITSUBISHI IGBT MODULES
APM/Pixhawk Power Module V6.0 Output BEC 3A XT60 Plug 28V 90A
- Input Voltage Range: 6-28V DC
- Output voltage: 5.3V ± 0.1V
- Maximum output current: 3A
- Maximum current: 90A
- Maximum voltage: 30V
- Supports from 2 cell to 6 cell battery.
- 6P cable can be directly connected to APM/Pixhawk flight control
- Additional 4P rows of pin-free to wire/PIN to connect to another flight control
- Voltage and current measurement configured for 5V ADC.
- Switching regulator outputs 5.3V and 3A max.
- Dimensions: 25mm x 21mm x 9mm
- Weight: 17gm
AD590 Temperature Transducer IC
- 2-Terminal IC Temperature Transducer
- Linear current output: 1 μA/K
- Wide temperature range: −55°C to +150°C
- Probe-compatible ceramic sensor package
- 2-terminal device: voltage in/current out
- Laser trimmed to ±0.5°C calibration accuracy (AD590M)
- Excellent linearity: ±0.3°C over full range (AD590M)
- Wide power supply range: 4 V to 30 V
- Sensor isolation from case
- Operating Voltage:30V
PIC18F4520 Microcontroller IC
- Maximum CPU Frequency: 40 MHz
- Architecture: 8 bit
- Program Memory (Flash): 32 kB
- RAM: 1536 byte
- Internal Oscillator: 8MHz, 32 KHz
- ADC: 1 (13 channels)
- of Pins: 40
- Voltage: 2V - 5.5V
- C Compiler Optimized Architecture: - Optional extended instruction set designed to optimize re-entrant code
- 100,000 Erase/Write Cycle Enhanced Flash Program Memory Typical
- 1,000,000 Erase/Write Cycle Data EEPROM Memory Typical
- Flash/Data EEPROM Retention: 100 Years Typical
- Self-Programmable under Software Control
- Priority Levels for Interrupts
- 8 x 8 Single-Cycle Hardware Multiplier
- Extended Watchdog Timer (WDT): - Programmable period from 4 ms to 131s
- Single-Supply 5V In-Circuit Serial Programming™ (ICSP™) via Two Pins
- In-Circuit Debug (ICD) via Two Pins
- Wide Operating Voltage Range: 2.0V to 5.5V
- Programmable Brown-out Reset (BOR) with Software Enable Option
AD633 Analog Multiplier IC
- Analog Multiplier
- Four-Quadrant Multiplication
- Low Cost 8-Lead Package
- Complete—No External Components Required
- Laser-Trimmed Accuracy and Stability
- Total Error Within 2% of FS
- Differential High Impedance X and Y Inputs
- High Impedance Unity-Gain Summing Input
- Laser-Trimmed 10 V Scaling Reference
- Supply Voltage:18V
PIC18F4550 Microcontroller IC
- Maximum CPU Frequency: 48 MHz
- Architecture: 8 bit
- Program Memory (Flash): 32 kB
- RAM: 2048 byte
- Internal Oscillator: 8MHz, 32KHz
- ADC: 1 (13 channels)
- of Pins: 40
- Voltage: 2V - 5.5V
- C Compiler Optimized Architecture with optional Extended Instruction Set
- 100,000 Erase/Write Cycle Enhanced Flash Program Memory typical
- 1,000,000 Erase/Write Cycle Data EEPROM Memory typical
- Flash/Data EEPROM Retention: > 40 years
- Self-Programmable under Software Control
- Priority Levels for Interrupts
- 8 x 8 Single-Cycle Hardware Multiplier
- Extended Watchdog Timer (WDT): - Programmable period from 41 ms to 131s
- Programmable Code Protection
- Single-Supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins
- In-Circuit Debug (ICD) via two pins
- Optional dedicated ICD/ICSP port (44-pin devices only)
- Wide Operating Voltage Range (2.0V to 5.5V)
ANTENNA WIFI
Antenna Specifications:
- Color: Black
- Radiation: Omni-directional
- Gain:8dBi
- Frequency Range(MHz): 2400-2500, 5150-5850MHz
- Connector Type: RP-SMA Male (Hole)
- Angle Adjustable: 90° 135° 180°
- Dimension: 16cm/ 6.3”(Unbend) / 13.5cm/ 5.31”(Bend)
- Wight: 13.5g / 0.48 oz per antenna
- Color: Black & Gold
- Length: 15cm / 5.9''
- Wight:4.4g / 0.17 oz per pigtail cable
- Connector Type: U.FL/ IPEX to RP-SMA Female
MEGA328P Atmel Microcontroller IC
- Flash (Kbytes): 32 Kbytes
- Pin Count: 32
- Operating Freq. (MHz): 20 MHz
- CPU: 8-bit AVR
- Max I/O Pins: 23
- Ext Interrupts: 24
- SPI: 2
- UART: 1
- ADC channels: 8
- SRAM (Kbytes): 2
- EEPROM (Bytes): 1024
- Operating Voltage (Vcc): 1.8 to 5.5
- Package: PDIP 28P3 28
- High Performance, Low Power Atmel®AVR® 8-Bit Microcontroller Family
- Advanced RISC Architecture
- High Endurance Non-volatile Memory Segments
- Peripheral Features includes Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode,One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode,Real Time Counter with Separate Oscillator,8-channel 10-bit ADC , Programmable Serial USART,Master/Slave SPI Serial Interface
- Operating Voltage: 1.8 - 5.5V
AD705J Bipolar Operational Amplifier IC
AD536 Integrated Circuit RMS-DC Converter IC
- Integrated Circuit RMS-DC Converter
- True RMS To DC Conversion
- Laser Trimmed to High Accuracy
- 0.2% Max Error (AD536AK)
- 0.5% Max Error(AD536AJ)
- Wide Response Capability
- Computes RMS of AC and DC Signals
- 450kHz Bandwidth: Vrms>100mV
- 2 MHz Bandwidth: Vrms>1V
- Signal Crest Factor of 7 for 1% error
- DB Output With 60db Range
- Low Power:1.2mA Quiescent Current
- Single or Dual Supply Operation
- Monolithic Integrated Circuit
- -55C-+125C Operation(AD536AS)
PIC18F452 Microcontroller IC
- Maximum CPU Frequency: 40 MHz
- Architecture: 8 bit
- Program Memory (Flash): 32 kB
- RAM: 1536 byte
- Internal Oscillator: No
- ADC: 1 (8 channels)
- of Pins: 40
- Voltage: 2V - 5.5V
- 100,000 erase/write cycle Enhanced FLASH program memory typical
- 1,000,000 erase/write cycle Data EEPROM memory
- FLASH/Data EEPROM Retention: > 40 years
- Self-reprogrammable under software control
- Power-on Reset (POR), Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
- Watchdog Timer (WDT) with its own On-Chip RC Oscillator for reliable operation
- Programmable code protection
- Power saving SLEEP mode
- Selectable oscillator options including:
- Single supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins
- In-Circuit Debug (ICD) via two pins
- Low power, high speed FLASH/EEPROM technology
- Fully static design
- Wide operating voltage range (2.0V to 5.5V)
- Industrial and Extended temperature ranges
- Low power consumption:
PIC18F2550 Microcontroller IC
- Maximum CPU Frequency: 48 MHz
- Architecture: 8 bit
- Program Memory (Flash): 32 kB
- RAM: 2048 byte
- Internal Oscillator: 8 MHz, 32 KHz
- ADC: 1 (10 channels)
- of Pins: 28
- Voltage: 2V - 5.5V
- C Compiler Optimized Architecture with optional Extended Instruction Set
- 100,000 Erase/Write Cycle Enhanced Flash Program Memory typical
- 1,000,000 Erase/Write Cycle Data EEPROM Memory typical
- Flash/Data EEPROM Retention: > 40 years
- Self-Programmable under Software Control
- Priority Levels for Interrupts
- 8 x 8 Single-Cycle Hardware Multiplier
- Extended Watchdog Timer (WDT): - Programmable period from 41 ms to 131s
- Programmable Code Protection
- Single-Supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins
- In-Circuit Debug (ICD) via two pins
- Optional dedicated ICD/ICSP port (44-pin devices only)
- Wide Operating Voltage Range (2.0V to 5.5V)
