74LS59 AND OR INVERT Gate IC
74LS595 8-Bit Shift Register IC
74LS641 Octal Bus Transceiver IC
- Octal Bus Transceiver
- Output:Â Open-Collector
- Logic:Â True
- High-level output voltage:Â 5.5V
- Low-level output voltage:Â 0.25V
- High-level output current:Â 0.1mA
- Low-level output current:Â 24mA
- Input clamp voltage:Â -1.5V
- Propagation Delay Time Max.:Â 40ns
- Supply voltage range:Â 4.75 to 5.25V
- Package:Â DIP-20
74LS642 Octal Bus Transceiver IC
- Octal Bus Transceiver
- Output:Â Open-Collector
- Logic: Inverting
- High-level output voltage: 5.5V
- Low-level output voltage: 0.25V
- High-level output current: 0.1mA
- Low-level output current: 24mA
- Input clamp voltage: -1.5V
- Propagation Delay Time Max.: 60ns
- Supply voltage range: 4.75 to 5.25V
- Package: DIP-20
74LS645 Octal Bus Transceiver IC
74LS73 Dual Positive Pulse Triggered J-K Flip-Flop IC
74LS75 4-Bit Bistable Latch IC
- 4-Bit Bistable Latche
- High-level input voltage:Â 2V
- Low-level input voltage:Â 0.8V
- High-level output current: -400µA
- Low-level output current:Â 8mA
- No. of Circuits:Â 2
- No. of Inputs:Â 4
- No. of Outputs:Â 4
- Input clamp voltage:Â -1.5V
- Propagation delay time:Â 30ns
- Supply voltage range:Â 4.75 to 5.25V
- Package:Â DIP-16
74LS76 Dual J-K Flip-Flop IC with Set and Clear
74LS83 4-Bit Binary Adder IC
74LS85 4-Bit Magnitude Comparator IC
- Technology Family: LS
- VCC (Min): 4.75V
- VCC (Max): 5.25
- Bits (#): 4
- Operating Voltage (Nom): 5V
- The frequency at a normal voltage (Max): 35MHz
- Propagation delay (Max): 35ns
- IOL (Max): 16mA
- IOH (Max):-0.4mA
- Rating: Catalog
- Operating temperature range: 0°C to 70°C
- Available in 14-pin PDIP, GDIP, PDSO packages
74LS86 Quad 2-Input Exclusive-OR Gate IC
- Technology Family: LS
- Quad 2-Input Exclusive-OR Gate
- High-level input voltage: 2V
- Low-level input voltage: 0.8V
- High-level output current: -0.4mA
- Low-level output current: 8mA
- Input clamp voltage: -1.5V
- of gates: 4
- Propagation delay time: 23ns
- Supply voltage range: 4.75 to 5.25V
- Package: DIP-16
- Input type: TTL-Compatible CMOS
- Output type: Push-Pull
- High Speed (TPD 10-50ns)
- Data rate (Max): 35Mbps
- Operating temperature range: 0°C to 70°C
