CA3140 Operational Amplifier IC
74LS248 BCD to Seven Segment Decoder Driver IC
- BCD to Seven Segment Decoder/Driver
- Logic Family: 74LS
- Propagation Delay Time: 100 ns at 5 V
- Number of Lines In/Out: 4 / 7
- Operating Temperature Range: 00C to +700C
- Supply Voltage Range: 4.75V to 5.25V
- Internal Pull-Ups Eliminate Need for External Resistors
- Lamp-Test Provision
- Leading/Trailing Zero Suppression
- Package: DIP-16
UTC1240A Electronic Dual-Tone Ringer
LM7805 Positive Voltage Regulator IC
MOQ: 2 nos
- Output Voltage: 5V
- Line Regulation (max): 100mV
- Load Regulation (max): 120mV
- Dropout Voltage: 2V
- Output Resistance: 17mΩ
- Output current in excess of 1A
- Internal thermal overload protection
- No external components required
- Output transistor safe area protection
- Internal short circuit current limit
- Available in the aluminum TO-3 package
TOP261EN Off-line Switcher IC
PIC18F4550 Microcontroller IC
- Maximum CPU Frequency: 48 MHz
- Architecture: 8 bit
- Program Memory (Flash): 32 kB
- RAM: 2048 byte
- Internal Oscillator: 8MHz, 32KHz
- ADC: 1 (13 channels)
- of Pins: 40
- Voltage: 2V - 5.5V
- C Compiler Optimized Architecture with optional Extended Instruction Set
- 100,000 Erase/Write Cycle Enhanced Flash Program Memory typical
- 1,000,000 Erase/Write Cycle Data EEPROM Memory typical
- Flash/Data EEPROM Retention: > 40 years
- Self-Programmable under Software Control
- Priority Levels for Interrupts
- 8 x 8 Single-Cycle Hardware Multiplier
- Extended Watchdog Timer (WDT): - Programmable period from 41 ms to 131s
- Programmable Code Protection
- Single-Supply 5V In-Circuit Serial Programming™ (ICSP™) via two pins
- In-Circuit Debug (ICD) via two pins
- Optional dedicated ICD/ICSP port (44-pin devices only)
- Wide Operating Voltage Range (2.0V to 5.5V)
AP8022-AC-DC OFF LINE SMPS PRIMARY SWITCHER IC
- 85v to 265v wide range AC voltage input
- A 700v MOSFET on the same silicon chip
- Auto start up with high voltage current source
- PWM with current mode control
- 9v to 38v wide range VCC voltage
- Fixed 60KHz switching frequency
- Automatic skip cycle mode in low load condition.
- Over temperature, over current and over voltage protection
- Auxiliary under voltage lockout with hysteresis
- Available in SOP8 and DIP8 Package
74LS13 Dual 4-Input Schmitt Trigger IC
- 4-Input NAND gate Schmitt Trigger – Hex Inverter
- Operating Voltage: 5V
- Low Level Hysteresis voltage: 0.25V
- High Level Hysteresis voltage: 3.4V
- Output current High: -0.4mA
- Output current Low: 8.0mA
- Hysteresis voltage: 0.8V typically
- Typical Rise Time: 12nS
- Typical Fall Time: 12nS
- Available in 14-pin PDIP, GDIP, PDSO packages
UC3842A Current Mode Controller IC
- High Performance Current Mode Controller
- Bias and Drive Voltages: 30V
- Total Power Supply and Zener Current: 30mA
- Output Current: 1A
- Reference Output Voltage: 5V
- Line Regulation Max: 20mV
- Load Regulation Max: 25mV
- Frequency: 52KHz
- Low Level Output Voltage: 0.1V
- High Level Output Voltage: 13.5V
- Startup Threshold Max: 9V
- Package: DIP-8
- Optimized for Off-Line and DC to DC Converters
- Low Start Up Current (< 1 mA)
- Automatic Feed Forward Compensation
- Pulse-By-Pulse Current Limiting
- Enhanced Load Response Characteristics
- Under-Voltage Lockout with Hysteresis
- Double Pulse Suppression
- High Current Totem Pole Output
- Bandgap Reference
- Low Ro Error Amp
- Up to 500-kHz Operation
VIPER12A Low Power Offline SMPS Primary Switcher IC
- Drain Source voltage: 730V
- Off State Drain Current: 0.1mA
- Static drain-source ON state resistance: 27Ω
- of Outputs: 1
- Power dissipation: 8W
- Package: DIP-8
- Low power offline switched-mode power supply primary switcher
- Fixed 60 kHz switching frequency
- High voltage start-up current source
- Over temperature, over current and over voltage protection with auto-restart
AD633 Analog Multiplier IC
- Analog Multiplier
- Four-Quadrant Multiplication
- Low Cost 8-Lead Package
- Complete—No External Components Required
- Laser-Trimmed Accuracy and Stability
- Total Error Within 2% of FS
- Differential High Impedance X and Y Inputs
- High Impedance Unity-Gain Summing Input
- Laser-Trimmed 10 V Scaling Reference
- Supply Voltage:18V
